SS 2 Inch Water Solenoid Valve 24V Solenoid Valve Water RSP Series
SS 2 Inch Water Solenoid Valve 24V Solenoid Valve Water RSP Series
SS 2 Inch Water Solenoid Valve 24V Solenoid Valve Water RSP Series
SS 2 Inch Water Solenoid Valve 24V Solenoid Valve Water RSP Series
Specifications
Brand Name :
ROUND STAR
Model Number :
RSP
Certification :
ISO CE ROHS
Place of Origin :
CHINA (YUYAO CITY)
MOQ :
negotiation
Price :
USD
Payment Terms :
T/T, Western Union
Supply Ability :
consult
Delivery Time :
depend on the order quantity
Packaging Details :
package for exporting standard
voltage :
AC220～240V AC110V 50/60Hz 22VA DC24V DC12V 13W
interface size :
3/8＂ ～ 2＂
interface :
G thread NPT thread Rc thread
sealing material :
NBR(-5～80℃) EPDM VITON
working pressure :
0.3~16 bar
coil :
IP65 H degree
Description

RSP series 2-way pilot operated normally closed brass SS316 water air solenoid valve 3/8＂ ～ 2＂

RSP-series 2-way pilot operated(NC)solenoid valve specification table

(ES coil can match EPDM and VITON, but medium temperature must be ≤80℃)

interface

orifice

(mm)

Cv

 working pressure(bar)

medium

temperature

℃

sealing

material

coil

insulation

degree

 power

normal order code

min

pressure

 Max pressure normal coil Es coil

plastic seal

AC220V

G thread

sealing material:blank:NBR E:EPDM V:VITON

air gas

water hotwater

liquid light oil

 VA W

VA

W

AC

220

V

DC

24

V

AC

220

V

DC

24

V
AC DC brass SS316
3/8〃 13 4.5 0.3 16 16 80 NBR H 22 13 3 3 RSP-10-AC220V RSP-10J-AC220V
13 4.5 0.3 16 16 130 EPDM H 22 13 RSP-10-E-AC220V RSP-10J-E-AC220V
13 4.5 0.3 16 16 120 VITON H 22 13 RSP-10-V-AC220V RSP-10J-V-AC220V

1/2〃

 13 4.5 0.3 16 16 80 NBR H 22 13 3 3 RSP-15-AC220V RSP-15J-AC220V
13 4.5 0.3 16 16 130 EPDM H 22 13 RSP-15-E-AC220V RSP-15J-E-AC220V
13 4.5 0.3 16 16 120 VITON H 22 13 RSP-15-V-AC220V RSP-15J-V-AC220V
3/4〃 20 7.6 0.3 16 16 80 NBR H 22 13 3 3 RSP-20-AC220V RSP-20J-AC220V
20 7.6 0.3 16 16 130 EPDM H 22 13 RSP-20-E-AC220V RSP-20J-E-AC220V
20 7.6 0.3 16 16 120 VITON H 22 13 RSP-20-V-AC220V RSP-20J-V-AC220V
1〃 25 12 0.3 16 16 80 NBR H 22 13 3 3 RSP-25-AC220V RSP-25J-AC220V
25 12 0.3 16 16 130 EPDM H 22 13 RSP-25-E-AC220V RSP-25J-E-AC220V
25 12 0.3 16 16 120 VITON H 22 13 RSP-25-V-AC220V RSP-25J-V-AC220V

11/4〃

 32 24 0.3 16 16 80 NBR H 22 13 3 3 RSP-32-AC220V RSP-32J-AC220V
32 24 0.3 16 16 130 EPDM H 22 13 RSP-32-E-AC220V RSP-32J-E-AC220V
32 24 0.3 16 16 120 VITON H 22 13 RSP-32-V-AC220V RSP-32J-V-AC220V
11/2〃 40 30 0.3 16 16 80 NBR H 22 13 3 3 RSP-40-AC220V RSP-40J-AC220V
40 30 0.3 16 16 130 EPDM H 22 13 RSP-40-E-AC220V RSP-40J-E-AC220V
40 30 0.3 16 16 120 VITON H 22 13 RSP-40-V-AC220V RSP-40J-V-AC220V
2〃 50 48 0.3 16 16 80 NBR H 22 13 3 3 RSP-50-AC220V RSP-50J-AC220V
50 48 0.3 16 16 130 EPDM H 22 13 RSP-50-E-AC220V RSP-50J-E-AC220V
50 48 0.3 16 16 120 VITON H 22 13 RSP-50-V-AC220V RSP-50J-V-AC220V

SS 2 Inch Water Solenoid Valve 24V Solenoid Valve Water RSP Series

SS 2 Inch Water Solenoid Valve 24V Solenoid Valve Water RSP Series

Founded in 1965, Yuyao No.4 Instrument Factory has been a professional manufacturer of solenoid valves and has enjoyed an excellent reputation through the past more than 50 years in China. With the introduction of foreign cutting-edge technology, and the sustained innovation and self-improving, the company has mastered the key technology and is keeping pioneer position in the field of fluid solenoid valve.

The company is equipped with superior production machines, advanced process flows, complete testing systems; the products have sophisticated structure, reliable performance, fine outlook and reasonable price, covering over 40 series and 3000 specifications, having been exported to all over the whole world since 2004.
