Plastic Latching Liquid Water Solenoid Valve Pilot Operated DN 50MM 24VDC
Plastic Latching Liquid Water Solenoid Valve Pilot Operated DN 50MM 24VDC
Plastic Latching Liquid Water Solenoid Valve Pilot Operated DN 50MM 24VDC
Plastic Latching Liquid Water Solenoid Valve Pilot Operated DN 50MM 24VDC
Specifications
Brand Name :
Round Star
Model Number :
YSZ
Certification :
CE/ROHS/TUV/FDA
Place of Origin :
China
MOQ :
5pcs
Price :
negotiation
Payment Terms :
Western Union, MoneyGram, T/T
Supply Ability :
3,000pcs per month
Delivery Time :
10 working days after received your payment
Packaging Details :
Carton, wooden case, exporting condition
working medium :
liquid、water、air、light oil
medium temperature :
-5 ～ 80℃
working pressure :
0.3～16bar
working type :
DN1.5～4 direct acting DN15～50 pilot operated
valvebody material :
brass SS316 PA66
sealing material :
NBR
interface :
G thread NPT thread
working voltage :
DC6V DC9V DC12V DC24V 4W 6W 12W IP65 H degree
Description

YSZ-series pilot operated solenoid valve specification table

model

orifice size

( mm )

 Interface size Cv working pressure(bar)

length×width×height

( mm )

 weight(Kg)
air Water liquid brass SS PA66
YSZ - 15 14 1/2＂ 3.5 0.3～16 0.3～12 66×48×112 0.7 0.6
YSZ - 20 20 3/4＂ 7.6 0.3～16 0.3～12 75×58×118 0.8 0.7
YSZ - 25 25 1＂ 12 0.3～16 0.3～12 96×69×125 1.3 1.2
YSZ - 32 32 11/4＂ 22 0.3～16 0.3～10 131×96×125 2.8 2.8
YSZ - 40 40 11/2＂ 30 0.3～16 0.3～10 131×96×150 2.6 2.6
YSZ - 50 50 2＂ 48 0.3～16 0.3～10 168×128×165 3.9 3.6
YSZ–15SL 15 1/2＂ 3.5 0.3～7 0.3～7 85×73×126 0.6
YSZ–20SL 20 3/4＂ 7.6 0.3～7 0.3～7 90×73×128 0.6
YSZ–25SL 25 1＂ 12 0.3～7 0.3～7 125×90×148 0.6
YSZ–32SL 32 11/4＂ 22 0.3～7 0.3～7 150×128×173 0.8
YSZ–40SL 40 11/2＂ 30 0.3～7 0.3～7 152×128×176 0.9
YSZ–50SL 50 2＂ 48 0.3～7 0.3～7 170×140×190 1.1


Advantages Introduction

1, due to self-holding solenoid valves do not have long-term power, to achieve energy saving and environmental protection.

2, a fundamental solution to the long-term due to the solenoid valve coil is energized and burned embarrassing situation.

3, almost the entire control process no power, because the power to eliminate the potential safety problems.

Product Usage:
Suitable for normal pure gases or liquids, especially air, water, hot water, natural gas, diesel and other pipeline control system; widely used in mining equipment, cutting equipment, washing equipment, machinery manufacturing, bio-energy, health care and environmental protection water treatment and other industries.
