Easy to Operate Geological Drilling Rig Machine for Geologic Structure Prospecting
Easy to Operate Geological Drilling Rig Machine for Geologic Structure Prospecting
Specifications
Brand Name :
JINZHOU SHITAN
Model Number :
ST-200
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
2000 sets per year
Delivery Time :
7-10 days
Packaging Details :
Standard Export Package
Condition :
New
Power Type :
Diesel/Electricity
Power(W) :
14.7KW(20HP) Diesel
Dimension(L*W*H) :
1820*980*1400mm
Weight :
850KGS
Drilling Depth :
200m
Drill Rod Dia :
50mm
Max Torque :
2000N.m
Drilling Travel :
450mm
Cylinder Stroke :
400mm
Drill Mast Type :
Tower
Drill Tower Dimension :
2.4*2.2*7.2
Dimension :
1820x980x1400mm
Description

Easy to Operate Geological Drilling Rig Machine for Geologic Structure Prospecting

Product Application:

1. Adopted optimum technical preference, high mechanization, low labour intensity and high work efficiency.

2. Advanced power of China is used and the weight is light.Transmission mechanism in drilling machine gear box makes rapid hole clean up possible.

3. In its revolving plate, the newly installed bevel gear makes it running more smoothly, more adequate lubricate and long working life. The revolving plate could be moved away from the hole with the front frame to ensure a wider working room. Multiple drilling modes selectable.

4. Oil hydraulic driving equipped ensures easy handling and high efficiency. High pressure wheel oil pump is used for improving the lifting capacity. This is more useful for dealing with the accidents in the hole.

5. Optimised structure, small volume, light weight, easy to remove and install, convenient for moving, assembling and repairing. The machine can be divided into five parts and every part is lighter than 60Kg.

Product Parameter:

Basic Parameters
Drilling depth 200m
Drilling diameter 300mm
Drill pipe diameter 50mm
Gross weight(including the engine 850kg
Revolving Plate
Spindle speed 900 478 388 205 1 57 68 r/min
Spindle speed(reversal) 256 85
Maximum torque 2000N*m
Driving travel 450mm
Maximum Cylinder driving force 2,9000N
Maximum Cylinder lifting force 3,9000N
Lifter
Lifting capacity(single pipe) 3,0000N
Bobbin line speed (2 layers) 0.27 0.64 0.83 1.58 1.64 m/s
Rope diameter 12.5mm
Rope capacity 30m
Drive motor
Type ZS1110
Rated power 13.2KW

Easy to Operate Geological Drilling Rig Machine for Geologic Structure Prospecting
