Geological Exploration Core 15KW Water Well Rig
Geological Exploration Core 15KW Water Well Rig
Geological Exploration Core 15KW Water Well Rig
Geological Exploration Core 15KW Water Well Rig
Specifications
Brand Name :
JINZHOU SHITAN
Model Number :
GK-180
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
2000 sets per year
Delivery Time :
7-12 days
Packaging Details :
Standard Export Package
Condition :
New
Type :
Rotary Drilling Rig
Power Type :
Diesel
Usage :
Water Well
Voltage :
380V
Power(W) :
15KW
Weight :
1200KGS
Other name :
drill rig
Drill rod diameter :
42, 50mm
Description

Water Well Core Drilling Rig ,Geological Exploration Drilling Rig

Features of speed diamond core drilling rig for sale:

1.Construction drilling of the projects e.g. prospection, geotechnical investigation, railway, road, port, bridge,
water conservancy and hydropower, tunnel, well, industrial and civil construction;
2. Core mining exploration, Or exploration;
3. Small hole diameter water well drilling;
4. Geothermal pipe-installing for heat pump;
5. Small-diameter hole foundation piling drilling.

Technical parameters of speed diamond core drilling rig for sale:

Drilling rigs
Drilling depth 100, 180m
Hole termination diameter 110, 75mm
Holing diameter 150mm
Drill rod diameter 42, 50mm
Drill dip angle 90°~75°
Borehole overall size (L*W*H) 1433*697*1274m
Drill weight (power engine excluded) 420KG
Drill overall size (L*W*H) 1620*970*1560m
Drill weight (power engine excluded) 620KG
Drill overall size (L*W*H) 1700*780*1274m
Drill weight (power engine excluded) 490KG
Gyrator
Vertical shaft rotation speed 664, 128, 287, 557 r/min
Vertical shaft travel 450mm
Vertical shaft max. feeding pressure 15KN
Vertical shaft max. hoisting ability 25KN
Windlass
Single line max. hoisting ability 15KN
Drum rotation speed 121, 76, 36r/min
Drum peripheral speed (second floor) 0.166, 0.331, 0.733, 1.465m/s
Drum diameter 140mm
Steel wire line diameter 9.3mm
Oil pump
Hydraulic pump pressure 1.2Mpa
Outflow 8ml/r
Rating rotation speed 1500r/min
Power
Diesel engine model s1105
Rating rotation speed 2200r/min
Rating power 15KW
Rating rotation speed 1460r/min

Characteristics of drilling rig:

1. With hydraulic automatic feeding mechanism to improve drilling efficiency;
2. Adopting the autumn card blessing mechanism instead of the chuck, it can realize the non-stop bar and easy to operate;
3. Equipped with a hole bottom pressure gauge to facilitate the understanding of the inside of the hole;
4. Compact structure, concentrated handle, small footprint, light weight, strong decomposability, easy to handle.

Geological Exploration Core 15KW Water Well RigGeological Exploration Core 15KW Water Well RigGeological Exploration Core 15KW Water Well Rig
