Welded Stainless Steel Continuous Slot Screen For Water Well Drilling
Welded Stainless Steel Continuous Slot Screen For Water Well Drilling
Welded Stainless Steel Continuous Slot Screen For Water Well Drilling
Welded Stainless Steel Continuous Slot Screen For Water Well Drilling
Welded Stainless Steel Continuous Slot Screen For Water Well Drilling
Welded Stainless Steel Continuous Slot Screen For Water Well Drilling
Welded Stainless Steel Continuous Slot Screen For Water Well Drilling
Welded Stainless Steel Continuous Slot Screen For Water Well Drilling
Specifications
Brand Name :
Hengyuan
Model Number :
4" 6" 8" 10" 12" 14" 16"
Certification :
ISO,CIQ,SGS
Place of Origin :
Anping, Hebei, China
MOQ :
1 Piece
Payment Terms :
D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
300 Meters per day
Delivery Time :
10 days
Packaging Details :
Wooden boxes or plastic film
Name :
Welded Continuous Wedge Wire Screen
Material :
Stainless steel or Low carbon galvanized
Length :
2.9m Or 5.8m To Fit Container
Slot :
0.5mm, 0.75mm, 1.0mm,1.5mm etc
Enc Connection :
Welded Rings Or Male/Female Threaded
Surface :
Polished
Advantages 1 :
Large open area
Advantages 2 :
Energy saving
Wire size :
2*3.5mm, 2.2*3.5mm,3*4.6mm etc
Support rod :
ø3.8-6.0mm
Description

SS Welded Continuous Wedge Wire Screen for Water Well Drilling

Welded Continuous Wedge Wire Screen For Water Well Drilling Introduction :

1. Welded Continuous Wedge Wire Screen is made up of Vee-shaped wire and round support rod in each intersection welded together.

2. Each slot opening between adjacent wires is V-shaped, resulting from the special shape of the wire used to form the screen surface.

3. The V-shaped openings, designed to be non-clogging, are narrowest at the outer face and widen inwardly.It has the firm structure, high temperature resistant, corrosion resistance, good mechanical performance, long service life, safe and reliable, etc.

4. It also can be used for a variety of medium.

Name: Johnson screen,Water wire screen,Water well screen, Wire warp screen,Wedge wire screen,

Screen tube,Slotted tube,Wound screen,Continuous slot screen filter,Sand control screen,

Wedge wire screen pipe, Rotary filter drum,Oil screen.
Material: Stainless steel 304,316L,Non-magnetic SS, Low carbon galvanized,904L,Duplex steel etc.
Diameter: From 29-1300mm (Normal diameter is in the below table)
Slot: From 0.1-100mm (Normal slot 0.5mm, 0.63mm, 0.75mm, 1.0mm, 1.5mm, Pls refer to below table)
Length: From 100-6000mm (Normal length is 2.9m and 5.8m, to fit container)
Wrap wire:2*3.5mm,2.2*3.5mm,2.2*4.5mm,3*4.6mm,3*5mm,3*6mm,3*6.5mm,4*7mm etc.
Support rod:ø3.0-ø6.0mm round wire, Also can be Vee-shaped wire.
Ends:Welded rings/Plain beveled ends,Male/female threaded,Flange etc.

Use:Water Well,Waste Water Treatment,Water supply systems,Architecture & Construction

Food Processors & Beverage Screens,Environmental protection,Refining & Petrochemical,etc.

Welded Continuous Wedge Wire Screen Sizes:

Material: Low carbon galvanized or stainless steel.

Diameter: 2" 3" 4" 6" 8" 10" 12" 14" 16"

Slot size: 0.5mm, 0.75mm, 1.0mm in usual

Length: 2.9m or 5.8m to fit container

End connection:Male/female threaded couplings Or Welded rings/ Plain beveled ends

Structure principle: stainless steel wedge filter is a kind of used for screening and filtering of the metal mesh structure element, concrete strength, the strength, stiffness and bearing capacity, can be made into various shapes of the rigid screening filter
Scope of application: used with petroleum, chemical, pharmaceutical, water treatment, environmental protection, food and light paper and other industries.

These size is this form, are all normal size we make.

We can also any other sizes as your request.

Pls supply your drawing to us is ok
