220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL
220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL
220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL
220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL
220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL
220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL
220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL
220V/50Hz HPLC Liquid Chromatography Instrument With Injection Volume 1-100μL
Specifications
Brand Name :
Wayeal
Model Number :
LC3200
Place of Origin :
China
Certification :
CE
MOQ :
1 Unit
Price :
Negotitate
Packaging Details :
Wooden Case
Delivery Time :
30 Days
Payment Terms :
T/T
Supply Ability :
50 Units/Month
Product Name :
High Performance Liquid Chromatography Instrument
Number of Samples :
120 Positions
Linearity :
>0.9999
Interface :
USB/Ethernet
Power Supply :
220V, 50Hz
Flow Rate :
0.001-10mL/min
Wavelength Range :
190-800nm
Column Temperature :
4-85°C
Description

High Performance Liquid Chromatography(HPLC) System with Injection Volume 1-100 μL and 220V/50Hz

Description of High Performance Liquid Chromatogaphy Instrument:

Wayeal’s High Performance Liquid Chromatograph Instrument (HPLC) is a sophisticated chromatography instrument designed for high-precision chromatography applications. The HPLC instrument is specifically designed to ensure high performance, accuracy, and reproducibility. Its advanced hardware and software capabilities make it ideal for a wide variety of chromatography applications.

Technical Data of High Performance Liquid Chromatography Instrument

Manufacturer: Wayeal
Product Name: Liquid Chromatography Instrument
Working Power Supply 220V, 50Hz
Ambient Temperature 10~40°C
Relative Humidity 20~85%
Qualitative Repeatability ≤0.2%
Quantitative Repeatability ≤0.4%
High Pressure Constant Flow Pump
Flow Rate Range 0.001~10.000mL/min
Setting Step 0.001mL/min
Pressure Range 0~42MPa
Pressure Pulsation 0.1MPa
Flow Rate Set Error ±0.2%
Flow Rate Stability RSD≤0.06%
Gradient Error ±1%
Column Oven
Temperature Control Range 4~85°C
Temperature Stability ±0.02°C
Temperature Setting Resolution 0.1°C
Autosampler
Injection Volume Repeatability ＜0.5%RSD
Linearity ＞0.9999
Cross Contamination ＜0.002%
Injection Volume Accuracy Error ±1%
Sample Positions 120
Injection Volume 1~100μL
UV Detector
Baseline Noise ≤2.0*10-6Au
Baseline Drift ≤1*10-5Au/h
Mini Detection Concentration ≤3.0*10-9g/mL (naphthalene/methanol)
Spectral Range 188~900nm
Wavelength Error ≤±0.1nm
Wavelength Repeatability ≤±0.1nm
Linearity Range ≥103
DA Detector
Baseline Noise ≤4*10-5Au
Baseline Drift ≤3*10-5Au/h
Mini Detection Concentration ≤2*10-8g/mL
Spectral Range 190~800nm
Wavelength Error ≤±0.1nm
Wavelength Repeatability ≤±0.1nm
Linearity Range ≥ 104
ELS Detector
Baseline Noise ≤ 0.0037mV
Baseline Drift ≤ 0.0026mV/30min
Evaporation Gas Flow Range (0 ~ 3) SLM
Atomization Temperature Range Room temperature ~ 90℃
Evaporation Temperature Range Room temperature～110℃
Detection Chamber Temperature Range Room temperature～60℃
Input Air Pressure (4 ~ 7) bar
FL Detector
Baseline Noise ≤ 5×10-6 FU
Baseline Drift ≤ 2 × 10-5 FU/30min
Spectral Range (200 ~ 650) nm
Wavelength Error ± 0.1 nm
Linearity Range ≥ 104
RI Detector
Detection Range 0.25 ~ 512 μRIU
Linearity Range ≥ 600 μRIU
Response Time 0.1, 0.25, 0.5, 1, 1.5, 2, 3, 6 sec;
Cell Volume 8μL

Applications of High Performance Liquid Chromatography Instrument:

The Wayeal high performance liquid chromatography LC3200 is suitable for a variety of applications, including environmental analysis, pharmaceutical analysis, food safety analysis, forensic analysis, and biochemical research. It is an ideal choice for laboratories and research centers that demand high performance and accuracy. The instrument is capable of producing precise and accurate results with low levels of detection and quantification. Its advanced functionality and user-friendly interface make it easy to use and maintain.
