Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s
Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s
Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s
Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s
Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s
Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s
Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s
Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s
Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s
Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s
Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s
Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s
Specifications
Brand Name :
Wayeal
Model Number :
SFJ-231
Certification :
ISO, CE
Place of Origin :
Anhui, China
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
30 Pieces Per Month
Delivery Time :
30 days
Packaging Details :
One piece per wooden case
Product Name :
Helium Leak Detector
Power Supply :
AC220V, 50Hz/60Hz
Response Time(s) :
<1
Startup Time(min) :
≤2
Detectable Quality :
2,3,4(H2 , He3, He4)
Operating Temperature :
0-40ºC
Description

Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s

Introduction of Helium Leak Detector

The helium leak detector, or helium mass spectrometer, is an indespensable vacuum troubleshooting tool. The tracer gas, helium, is introduced to a test part that is connected to the leak detector. The helium leaking through the test part enters through the system and this partial pressure is measured and the results are displayed on a meter. Moreover, we also offer many helium detector accessories such as gas regulator valves, helium spray guns, helium sniffer probes, and calibrated helium leak standards, as well as hard-to-find boards, ion sources, filaments, seals, and throttles.

Parameters of Helium Leak Detec

Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s







Performance Indicators
 Minimum detectable leak rate
(Pa·m3/s)/ vacuum mode		 5.0×10-13
Minimum detectable leak rate
(Pa·m3/s)/ sniffer mode		 5.0×10-9
Response time(s) <1
Startup time(min) ≤2
Leakage detection range
(Pa·m3/s)		 5.0×10-13~1.0×10-3
Leakage rate display range
(Pa·m3/s)		 1.0×10-12~1.0×10-3
Maximum allowable leak detection pressure(Pa) 1330
Detectable quality 2,3,4(H2 , He3, He4)










Basic Configuration
 Man-machine interface 7 "color LCD Touch Screen
Ion source 2pcs, iridium coated yttrium oxide, automatic switching
I/O Input/output interface Eight inputs and eight outputs
Communication interface RS232/485,USB*2
MES interface Standard
Physical size of instrument
(W)×(D)×(H),mm		 645 x 678 x 965mm
Specifications of leak detection port DN25 KF
Power Supply AC220V,50HZ/60HZ
Operating temperature 0-40ºC
Power 1000W
Display language Both Chinese and English
Leakage rate display Figure, bar chart, curve chart

Optional Accessories of Helium Leak Detector

Spray probe, wireless remote control, 20 micron inlet filter, calibration leak, customized tooling, sniffer, leak detection chamber, helium pressure chamber, vaccum pump oil.

Applications of Helium Leak Detector

Medical Industry: Cochlear implant, cardiac pacemaker, cerebral pacemaker, endoscope, gastroscope, colonbscope, etc.

Traditional Vaccum Industry: Pump valve, casting, vacuum tube, gas pipe, bellows, LNG, steam, low tempefature tank truck, vacuum funace, vacuum coating, accelerator and so on.

Other Industries: Industrial process tools • power generation • high energy physics • research & development • nanotechnology instrumentation • small parts manufacturing

Methods of Helium Leak Detection

Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s

Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s

Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s

Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s

Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/sWayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s

Wayeal SFJ-231 Mobile Helium Leak Detector Machine Price 5.0×10-13 Pa·m3/s
