Specifications
Brand Name :
Wayeal
Model Number :
CEMS1200
Certification :
ISO, CE
Place of Origin :
Anhui, China
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
20 Pieces Per Month
Delivery Time :
15 days
Packaging Details :
One piece per wooden case
Measurement range :
0-100mg/m3
Size :
930×730×2010mm
Weight :
175KGS
Detector Gas :
SO2, NOX, O2
Product Name :
Continuous Monitoring System for Flue Gas Emission
Packing :
Wooden Case or Customized
Description

Environmental Monitoring System Continuous Monitoring System for Flue Gas Emission

Product Introduction

The complete set of continuous flue gas emission monitoring system launched by Wayeal not only can continuously monitor SO2, NOX, O2, soot concentration, flue gas temperature, pressure, flow rate, humidity and many other related parameters but also can count the emission rate and the total amount of emissions so that the data can be effectively managed.

Product Parameter

Environmental Monitoring System Continuous Monitoring System for Flue Gas Emission
Pretreatment Heat and Wet Method
Nitrogen Oxide Measurement Conversion Furnace
Pollutant Range

SO2 0-100/200mg/m3

NOX 0-100/200mg/m3

O2 0-25%
Humidity Meter Measurement Heat Resistance Method Humidity Meter
Flowmeter Measurement Pitot Tube Flowmeter
Oxygen Content Zirconia

Working Principle

Gaseous pollutant monitoring uses UV differential method to measure the flue gas SO2 , NOX content; the O2 content is measured by electrochemical method or zirconium oxide. The flue gas temperature is measured by a temperature sensor, the flue gas pressure is measured by a pressure sensor, the flue gas flow rate is measured by a Pitot tube, and the flue gas humidity is measured by a high-temperature capacitive humidity sensor. And all the measurement signals are sent to the data acquisition and processing system.

Industry Application

Thermal power plant, steel plants, cement plants, chemical plants, etc.
