Laboratory Use High Pressure Ion Chromatography Instrument 35Mpa
Laboratory Use High Pressure Ion Chromatography Instrument 35Mpa
Laboratory Use High Pressure Ion Chromatography Instrument 35Mpa
Laboratory Use High Pressure Ion Chromatography Instrument 35Mpa
Laboratory Use High Pressure Ion Chromatography Instrument 35Mpa
Laboratory Use High Pressure Ion Chromatography Instrument 35Mpa
Specifications
Brand Name :
Wayeal
Model Number :
IC6200
Certification :
ISO, CE
Place of Origin :
Anhui, China
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
30 Pieces Per Month
Delivery Time :
30 days
Packaging Details :
Wooden Case
Product Name :
Ion Chromatography Instrument
Application :
Ions Analysis
Power Supply :
220V, 50~60Hz
Pump Material :
PEEK
Eluent :
KOH,Carbonate or MSA
Autosampler :
48 or 120 positions
Description

Laboratory Use High Pressure Ion Chromatography Instrument 35Mpa

Introduction of Ion Chromatography Instrument

Ion chromatography instrument is a kind of high performance liquid chromatography, so it is also called high performance ion chromatography (HPIC). Its resin has high cross-linking and low exchange capacity, and the injection volume is very small.

Characteristics of Ion Chromatography Instrument

1. Intergrated design and compact structure, minimizing connections between components.
2. 7.0" high brightness LCD touch operation interface, synchronized with the chromatography workstation, clearly displays the working statusOne-button operation, the system can realize automatic cleaning after the analysis is completed to ensure the cleaning performance.
3. One-touch maintenance": one-touch operation, the system can realize automatic maintenance of the instrument without manual operation, extending the service life of instrument.
4. Full PEEK pump and electric injection valve.

5. One-button operation, the system can realize automatic cleaning after the analysis is completed to ensure the cleaning perforamnce.

Technical Data of Ion Chromatography Instrument

In Line Eluent Generation Ion Chromatograph Instruments With Conductivity Detector
System Parameter
Qualitative Repeatability ≤0.5%
Quantitative Repeatability ≤1%
Pump System
Flow Rate (0.001～10.000)mL/min
Pump Head Pressure Resistance (0 ~ 35) Mpa
Flow Rate Setting Inaccuracy <0.1%
Flow Stability <0.1%
Pressure Display Accuracy 0.01Mpa
Pressure Pulsation <0.5%
Conductivity Detector
Baseline Noise ≤0.1%FS
Baseline Drift ≤0.5%FS
Minimum Detectable Concentration (Cl) ≤0.0002μg/mL
Minimum Detection Concentration (Li) ≤0.0001μg/mL
Conductivity Cell Volume ≤ 0.6μL
Conductivity Detection Range 0-15000μS/cm
Detector Resolution 0.00238nS/cm
Conductivity Cell Temperature Setting Error ±0.01°C
Resolution of Conductivity Cell Temperature Display 0.001°C
Suppressor
Constant Current Source Range 0-500mA in 0.1mA increments
Column Oven
Temperature Range Room temperature +5°C~85°C
Control Temperature Stability ≤ 0.1°C
Autosampler
Number of Sample Vials ≥ 120 (1.5mL standard sample bottle)
Repeatability

Full loop injection < 0.3% RSD,

Partial injection < 0.5% RSD,

Non-destructive injection < 1 % RSD (injection volume > 5μL)
Syringe Size Standard: 500μL; optional; 250μL, 1000μL, 2500μL
Loop Size Standard: 100μL; optional: 20μL, 50μL, 200μL
Linearity >0.999
Cross-contamination <0.01%
Eluent Generator
Flow Rate Range 0.001 to 3.000mL/min
Eluent Concentration Range KOH, MSA-0.1 to 100mM
Concentration Accuracy 0.1mM
Original Concentration of Electrolyte 25% KOH/MSA
Volume of Electrolyte 1000mL
Maximum Working Pressure 21Mpa (3000psi)
Gradient Accuracy 1.5%

Industry Application

Environment, food, medicine, agriculture, grain and oil, and chemical industry
