Advanced 120-Position Autosampler High Performance Liquid Chromatography System
Advanced 120-Position Autosampler High Performance Liquid Chromatography System
Advanced 120-Position Autosampler High Performance Liquid Chromatography System
Advanced 120-Position Autosampler High Performance Liquid Chromatography System
Advanced 120-Position Autosampler High Performance Liquid Chromatography System
Advanced 120-Position Autosampler High Performance Liquid Chromatography System
Advanced 120-Position Autosampler High Performance Liquid Chromatography System
Advanced 120-Position Autosampler High Performance Liquid Chromatography System
Specifications
Brand Name :
Wayeal
Model Number :
LC3200
Place of Origin :
China
Certification :
CE
MOQ :
1 Unit
Price :
Negotiate
Packaging Details :
Wooden Case
Delivery Time :
30 Days
Payment Terms :
T/T
Supply Ability :
30 Units/Month
Number of Samples :
120 Positions
Weight :
188Kg
Column Temperature :
4-85°C
Product Name :
Liquid Chromatography Instrument
Linearity :
>0.9999
Model :
LC3200
Injection Volume :
1-100μL
Interface :
USB/Ethernet
Description

Description of High Performance Liquid Chromatography Instrument:

The LC3200 liquid chromatography instrument is a versatile, reliable, and efficient HPLC instrument that is perfect for laboratories that demand high throughput, accurate, and reproducible results. Whether you are performing quantitative analysis or qualitative analysis, this HPLC instrument delivers exceptional performance and provides an efficient solution for your laboratory needs. The LC3200 model is equipped with 120 positions, allowing for high throughput sample analysis without the need for manual intervention.

Technical Data of High Performance Liquid Chromatography Instrument:

Manufacturer: Wayeal
Product Name: Liquid Chromatography Instrument
Working Power Supply 220V, 50Hz
Ambient Temperature 10~40°C
Relative Humidity 20~85%
Qualitative Repeatability ≤0.2%
Quantitative Repeatability ≤0.4%
High Pressure Constant Flow Pump
Flow Rate Range 0.001~10.000mL/min
Setting Step 0.001mL/min
Pressure Range 0~42MPa
Pressure Pulsation 0.1MPa
Flow Rate Set Error ±0.2%
Flow Rate Stability RSD≤0.06%
Gradient Error ±1%
Column Oven
Temperature Control Range 4~85°C
Temperature Stability ±0.02°C
Temperature Setting Resolution 0.1°C
Autosampler
Injection Volume Repeatability ＜0.5%RSD
Linearity ＞0.9999
Cross Contamination ＜0.002%
Injection Volume Accuracy Error ±1%
Sample Positions 120
Injection Volume 1~100μL
UV Detector
Baseline Noise ≤2.0*10-6Au
Baseline Drift ≤1*10-5Au/h
Mini Detection Concentration ≤3.0*10-9g/mL (naphthalene/methanol)
Spectral Range 188~900nm
Wavelength Error ≤±0.1nm
Wavelength Repeatability ≤±0.1nm
Linearity Range ≥103
DA Detector
Baseline Noise ≤4*10-5Au
Baseline Drift ≤3*10-5Au/h
Mini Detection Concentration ≤2*10-8g/mL
Spectral Range 190~800nm
Wavelength Error ≤±0.1nm
Wavelength Repeatability ≤±0.1nm
Linearity Range ≥ 104
ELS Detector
Baseline Noise ≤ 0.0037mV
Baseline Drift ≤ 0.0026mV/30min
Evaporation Gas Flow Range (0 ~ 3) SLM
Atomization Temperature Range Room temperature ~ 90℃
Evaporation Temperature Range Room temperature～110℃
Detection Chamber Temperature Range Room temperature～60℃
Input Air Pressure (4 ~ 7) bar
FL Detector
Baseline Noise ≤ 5×10-6 FU
Baseline Drift ≤ 2 × 10-5 FU/30min
Spectral Range (200 ~ 650) nm
Wavelength Error ± 0.1 nm
Linearity Range ≥ 104
RI Detector
Detection Range 0.25 ~ 512 μRIU
Linearity Range ≥ 600 μRIU
Response Time 0.1, 0.25, 0.5, 1, 1.5, 2, 3, 6 sec;
Cell Volume 8μL

Applications of High Performance Liquid Chromatography Instrument:

The Wayeal LC3200 is suitable for a wide range of scenarios that require accurate and precise analysis of various samples. It is widely used in research laboratories, pharmaceutical and biotech companies, food and beverage industries, environmental monitoring agencies, and many other fields.
