Specifications
Brand Name :
WAYJUN
Model Number :
DIN11 IAP-5AAC-P□ - V/I□
Certification :
CE approved
Place of Origin :
CN
Payment Terms :
T/T, Western Union,paypal
color :
green
isolation :
3000VDC
mounting :
DIN35 rail
Description

Features:
>>Input Range:0~500mAAC~5AAC
>>DC voltage/current signal output
>>Isolation Voltage:2500VDC
>>Accuracy: 0.5
>>Installation: DIN35 rail mounted
>>Industrial temperature range: - 40 ~ + 85 deg.C
Summary:
WAYJUN AC current signal isolated transmitter adopts the magnetic isolation technology advanced, capable of isolating inspection / monitoring of AC voltage signal, the product has the advantages of small volume, low power consumption, high precision. A single-phase, three-phase three wire and three-phase four wire multi. Between the input and output and auxiliary power supply can withstand 2500VDC isolation voltage, all output multiple products are isolated from each other, can be flexibly applied. Widely used in electric power, chemical, petroleum, industrial and automation fields.

Products Listing:
DIN11 IAP – 5AAC - P□ - V/I□
Input Signal
Power Supply
Output Signal
input Range
Power
code
output
code
0~500mA~5AAC
24VDC
P1
0-20mA
A3
12VDC
P2
4-20mA
A4
5VDC
P3
user-defined
 Az
15VDC
P4
0-5V
 V1
220VAC
P5
0-10V
 V2
user-defined
Vz
products samples:


1:Input:0-5AAC Power supply:24V output:4-20ma
Part No.:DIN11 IAP-5AAC-P1-A4
2:Input:0-500mAAC Power supply:24V output:4-20ma
Part No.:DIN11 IAP-0.5AAC-P1-A4
3:Input:0-5AAC Power supply:220VAC output:4-20ma
Part No.:DIN11 IAP-5AAC-P5-A4

Note:
1. Before using, according to packing lists, and product labels, check the quantity, models and specifications
2. When measure the signal directly, please set the terminal tighten
3. There are no damaged insulation, conductive dust and corrosive fumes of metal in the environment
4. Installation pitch ≥10mm
5. We have adjusted well, do not adjust arbitrarily
6. Warranty: two years. But if clients damage products by themselves or tear off any labels on the product, we can not
exchange
7. Products can not been used in strong magnetic field
8. Internal no anti-lightning circuit
9. Specifications subject to change without notice
Warranty
Two Years

more details,please check: http://www.wayjun.net/Datasheet/Signal/0-5A%20AC%20Current%20Signal%20Isolated%20Transmitter.pdf
