Specifications
Brand Name :
Superb Tent
Model Number :
AFRAMETENT01
Certification :
ISO9001, SGS
Place of Origin :
GUANGZHOU CHINA
MOQ :
1 set
Price :
From USD 5000 / set
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100 sets per month
Delivery Time :
10-15 days
Packaging Details :
Wooden case, PVC bags
Frame Material :
Aluminum and Hot dip galvanized steel
Roof Cover :
850g/sqm double coated PVC fabric
Glass Walls :
Tempered glass 6mm
Ceiling Material :
Fire proof satin fabric
Life span :
30 years
Sort :
Clear Span Tent
Description

Clear Span Large Transparent Glass Wall Marquee Outdoor Weather Resistant

Super Standard Tent could be widely used for temporary outdoor exhibitions,wedding parties, festival celebrations,conferences,sports and other events, and also good solution of temporary warehouses, workshops and temporary emergency relief and other purposes. There is no pole inside the tent, 100% interior space could be used. Full line accessories are available, windows sidewalls or plain PVC sidewalls are optional.

Description:

1) Size: from 6meters to 60meters

2) Eave height: standard from 2.5m, 3m, 4m to 5m upon span width (or special height per requested)

3) Length: Unlimited, extended by 3m or 5m each bay

Clear Span Large Transparent Glass Wall Outdoor Marquee Tent Weather Resistant

Clear Span Large Transparent Glass Wall Outdoor Marquee Tent Weather Resistant

2. Features:

No exterior guy ropes or staking required.


No pole inside,100% interior space be used.


Roof and gable vent is available.


Relocatable, easy to install, dismantle and transport.


Full line accessories available.

Clear Span Large Transparent Glass Wall Outdoor Marquee Tent Weather Resistant


3. Frame:

No maintenance required.


Extruded 4 channel aluminum hollow profiles with anodized finishing above 12um.


All steel connectors including small parts have galvanized finishing above 60um.


Modular character for diverse combination and expansion.

Clear Span Large Transparent Glass Wall Outdoor Marquee Tent Weather Resistant

4. Common Tent Sizes Recommendation

Clear Span Large Transparent Glass Wall Outdoor Marquee Tent Weather ResistantClear Span Large Transparent Glass Wall Outdoor Marquee Tent Weather Resistant

Style People capacity Suggested Tent sizes Area Side height
Dinner setting
(Event)
100 10x10m 100 ㎡ 2.5m
200 10x20m 200 ㎡ 2.5m
300 15x20m 300 ㎡ 3m
500 15x35m 525 ㎡ 3m
1000 20x50m 1000 ㎡ 4m
2000 30x70m 2100 ㎡ 4m

Clear Span Large Transparent Glass Wall Outdoor Marquee Tent Weather Resistant

Style People capacity Suggested Tent sizes Area Side height
Theater setting
(Church)
200 10x10m 100 ㎡ 2.5m
300 10x20m 200 ㎡ 2.5m
500 15x20m 300 ㎡ 3m
1000 15x35m 525 ㎡ 3m
2000 20x50m 1000 ㎡ 4m
3000 30x50m 1500 ㎡ 4m

Kedered roof fabric and sidewalls provide weather-proof tight coverings.


Bar tensioning roof & sidewalls system.


Different brand fabric for option: China Fabric,Ferrari,Sioen,Verseidag.

5. Tent Accessories Options

Clear Span Large Transparent Glass Wall Outdoor Marquee Tent Weather Resistant

6. Life span

Life span of fabric(cover & sidewalls): 8-10years;

Life span of aluminum frame: 20-30years

Romantic waterproof Pvc Cover Customized Luxury 210 People Wedding Tent Clear

Clear Span Large Transparent Glass Wall Outdoor Marquee Tent Weather Resistant

7.Structure safety parameters

Wind load: 100km/h (0.5km/sq.m.)

Snow load: 25kg/sq.m.

Romantic waterproof Pvc Cover Customized Luxury 210 People Wedding Tent Clear

Clear Span Large Transparent Glass Wall Outdoor Marquee Tent Weather Resistant

8.Color available:

White, red, yellow, blue, green, black, grey, transparent etc .
