Glass Wall TFS Tent UV Resistant / 20 By 20 Tent For Exhibiton
Glass Wall TFS Tent UV Resistant / 20 By 20 Tent For Exhibiton
Glass Wall TFS Tent UV Resistant / 20 By 20 Tent For Exhibiton
Glass Wall TFS Tent UV Resistant / 20 By 20 Tent For Exhibiton
Glass Wall TFS Tent UV Resistant / 20 By 20 Tent For Exhibiton
Glass Wall TFS Tent UV Resistant / 20 By 20 Tent For Exhibiton
Specifications
Brand Name :
LIRI TENT
Model Number :
CBT
Certification :
ISO9001:2008, SGS, TUV, CFM, IFAI, etc.
Place of Origin :
CHINA( Mainland), Guangdong
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100,000sqm/month
Delivery Time :
within 20 days
Packaging Details :
1 . membrane film. 2. Carton . 3. PVC carry bag .
Optional Accessories :
Glass Walls , ABS Walls , Ect
Color :
White , Red , Black , Green And More
Wind Resistance :
100 Km/h
Connectors :
Hot-DIP Galvanized
Fixing Solution :
Ground Anchor, Expandable Bolt
Frame :
High Pressed Extrued Aluminum Alloy
Description

Glass Wall TFS Tent UV Resistant / 20 By 20 Tent For Exhibiton

TFS Tent Reputation :

1. The first tent manufacturer established in 1997 in China.
2 . The largest tent manufacturer in China which covers 30, 000sqm and including 20, 000sqm building area.
3 . The most reliable tent supplier. Exported to over 80 countries, and maintaining excellent reputation,
4 . The NO. 1 tent exporter for four years in China.
5 . Engieer's Company, the owner of Liri Tent is more concern quality and safety than you.

Description :

It is widely used for exhibiton, golfing, tennis, horse racing, motor sport or any other type of events, our innovative and user- friendly Two StoryTent systems are a sure winner every time. We can enlarge the tent with the modular bay as well as diminish the tent size according to your specific requirement, making your events more special and attractive.

Specifications :

Type

Span Width

Bay Distance

Eave Height

Ridge Height

Main Profile

CBT

15m/49.2'

5m/16.4'

3.87m

8m

204x120x4mm(4-channel)

CBT

20m/65.6'

5m/16.4'

3.87m

8.8m

204x120x4mm(4-channel)

CBT

25m/82'

5m/16.4'

3.87m

9.9m

204x120x4mm(4-channel)

CTH

20m/65.6'

5m/16.4'

3.89m

8.9m

300x120x5mm(4-channel)

CTH

25m/82'

5m/16.4'

3.89m

10m

300x120x5mm(4-channel)

CTH

30m/98.4'

5m/16.4'

3.89m

11.2m

300x120x5mm(4-channel)

CTH

40m/131.2'

5m/16.4'

3.89m

13.5m

300x120x5mm(4-channel)

The length can be extended by 5m bay such as 15m,20m,30m,40m...Customized size or shape is available.

Structure :


Framework: hard pressed extruded aluminum 6061/T6(15HW) which can last more than 20 years.
Fabric Cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
Connector: strong hot-dip galvanized steel
Allowed Temperature Condition: -30 degree Celsius~+70 degree Celsius
Wind Loading: max. 100km/h (can be reinforced)
Snow Loading: 30kg/sqm (snow can't stay if use big degree roof pitch design)
Easy to be assembled and dismantled, movable.
No pole inside, 100% available interior space.

Packages:

1. aluminum frame packed in membrane film

2. hardware packed in solid carton box

3. roof and sidewall in professional PVC carry bag

Flooring :

Glass Wall TFS Tent UV Resistant / 20 By 20 Tent For Exhibiton

Glass Wall TFS Tent UV Resistant / 20 By 20 Tent For Exhibiton
