Life Span:

For the structure of the tent, it is strong enough for permanent or semi - permanent. The frame is using the 6064/ T6 aluminum frame, and it can use for about 20-25 years. If for the pvc roof cover, it can use for about 8 - 10 years.

Structure

Framework: hard pressed extruded aluminum 6061/T6(15HW) which can last more than 20 years.
Fabric Cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
Connector: strong hot-dip galvanized steel
Allowed Temperature Condition: -30 degree Celsius~+70 degree Celsius
Wind Loading: max. 100km/h (can be reinforced)
Snow Loading: 30kg/sqm (snow can't stay if use big degree roof pitch design)
Easy to be assembled and dismantled, movable.
No pole inside, 100% available interior space.

• If it is concrete ground , pls use the expandable bolts
• If it is termac grond or grass ground or sand ground or other soft gronds , pls use the steel anchors .
• If it is marble or tile ground or other kind indestructible grounds , pls use the weight plates system
• If you will make the concrete bases to fix the tent , pls use the embeded bolts M 24 x 500 mm

Usage

1. Exhibition

2. Event center

3. Sports center

4. Church

5. Warehouse

.....

Optional Accessories

• Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
• Wooden Flooring System: VIP cassette flooring, simple cassette flooring
• Doors: double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
• Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
• Fixing Methods: ground anchors, weight plate, expandable bolts
• Rain Gutters:inner roof beam rain gutter or rain gutter between two similar tents
• Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.
• Adjustable flooring system, can fix on the uneven land

Packaging:

• aluminum frame packed in membrane film
• hardware packed in solid carton box
• roof and sidewall in professional PVC carry bag
