Specifications
Brand Name :
LIRI TENT
Model Number :
BT 15m
Certification :
ISO9001:2008, SGS, TUV, CFM, IFAI, etc.
Place of Origin :
CHINA( Mainland), Guangdong
MOQ :
1 set
Price :
negotiable
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
100,000sqm/month
Delivery Time :
within 20 days
Packaging Details :
1 . membrane film. 2. Carton . 3. PVC carry bag .
Function :
Outdoor Party & Celebration
Model :
BT 15M
Side Walls :
Block Out White pvc sidewalls
Life Span :
20 - 25 years for the frame , 8 - 10 years for the roof
Width :
15m
Fixing Methods :
Weight plate system
Description
Tent Fixing Methods
  • If it is concrete ground , pls use the expandable bolts
  • If it is termac grond or grass ground or sand ground or other soft gronds , pls use the steel anchors .
  • If it is marble or tile ground or other kind indestructible grounds , pls use the weight plates system
  • If you will make the concrete bases to fix the tent , pls use the embeded bolts M 24 x 500 mm

Simple White PVC Marquee Tent With Plain PVC Sidewalls for Temporary 300 Guest Gathering


Applications:

Dimension Clear Span Eave Height Bay Distance
BT10 10m 4m 5m
BT 15 15m 4m 5m
BT20 20m 4m 5m
BT25 25m 4m 5m
Length No limitation
Main Structure Profile 204*120*4m

Tent size for the tent is very flexible, it tent width for the tent structure could from 3-80m . With different design, decoration, height and so on. It is suitable for different kind of outdoor event function. It is very easy for the installation and dismantle.


Optional Accessories

  • Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
  • Wooden Flooring System: VIP cassette flooring, simple cassette flooring
  • Doors: double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
  • Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
  • Fixing Methods: ground anchors, weight plate, expandable bolts
  • Rain Gutters:inner roof beam rain gutter or rain gutter between two similar tents
  • Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.

To make our customers access to one-stop shop service , Liri Tent provides all kinds of accessories and equipments for events including tent air conditioner which can refrigerate and heat and dehumidify . To meet the need for different kinds of spaces, there are several options for air conditioners such as 5 HP , 10 HP, 20 HP , 30 HP and 40 HP. Unified design makes our tent air conditioner easy to operated and possible to be installed both outside and inside.

Description:

The big tent series size from 10 m - 25 m , it can use for different kinds of events , warehouse , and more. This series of tent can fix with full line accessories .

Simple PVC Marquee Tent With Plain PVC Sidewalls For 300 Guest Gathering

Structure


Framework: hard pressed extruded aluminum 6061/T6(15HW) which can last more than 20 years.
Fabric Cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
Connector: strong hot-dip galvanized steel
Allowed Temperature Condition: -30 degree Celsius~+70 degree Celsius
Wind Loading: max. 100km/h (can be reinforced)
Snow Loading: 30kg/sqm (snow can't stay if use big degree roof pitch design)
Easy to be assembled and dismantled, movable.
No pole inside, 100% available interior space.

System Features

1. Cler span design , 100% interior space available

2. Easy to set up at all kinds of ground

3. Modular system , able to flexibly extend and move

4. Cost effective than fixed structure

5. Customized design for field requiremetns available

6. Durable materials of aluminum frame and pvc roof cover

Life Span:

For the structure of the tent, it is strong enough for permanent or semi - permanent.

1. The frame is using the 6061/ T6 aluminum frame, and it can use for about 20-25 years.

2. For the pvc roof cover, it can use for about 8 - 10 years.

If some parts need to update or replaces, just go back to us, and we could have the perfect match parts and will not influencethe structure.
