20m X 40m X 8m Luxury Glass Wall Flat Roof AluminumTents For Office
At the beginning of the design, Liri’s technicians will carefully communicate with customers, satisfying customers’ needs for architectural styles as much as possible, and customize their own temporary office buildings, whether temporary or permanent, Liri can offer you the perfect solution. The reason why the tent is used for office is that it has three characteristics temporary, flexible and movable. The building is not restricted by the site and can be set up and dismantled at any time, to meet the needs of different venues. Moreover, there is no pole support inside the tent, and 100% space utilization is very suitable for the office layout.




Dimension | Clear Span | Eave Height | Ridge Height | Bay Distance |
NPT | 6m | 2.6m | 3.71m | 3m |
NPT | 10m | 2.6m | 4.4m | 3m |
ET | 15m | 3.3m | 5.62m | 5m |
BT | 25m | 4m | 7.88m | 5m |
EBT | 30m | 4m | 8.9m | 5m |
TH | 40m | 5m | 10.4m | 5m |
LH | 50m | 5m | 12m | 5m |
Main Profile | 100x48x3mm, 204x120x4mm, 256x121x5mm, 300x120x5mm... |
Specifications & Features
- Framework: hard-pressed extruded aluminum 6061/T6(15HW) which can last over 20 years.
- Roof Cover: high-quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear-resistant, self-cleaning, etc.
- Connector: strong hot-dip galvanized steel
- Allowed Temperature Condition: -30 degrees Celsius~+70 degree Celsius
- Wind Loading: max. 100km/h (can be reinforced)
- Snow Loading: 30kg/sqm
- Easy to be assembled and dismantled, moved from place to place.
- No pole inside, and 100% available interior space.
Optional Accessories
- Windows: transparent PVC fabric, glass windows...
- Roof Shape: regular A shape, dome roof, polygonal, curved roof...
- Doors: PVC sliding doors, double-wing glass doors...
- Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall...
- Fixing Tools: steel anchors, weight plate, expandable bolts...
- Rain Gutters: inner roof beam rain gutter or rain gutter between two similar tents
- Other Optional Items: printing, lighting, air conditioning, sports flooring, installation tools, etc.
Packing
- Aluminum frame packed in membrane film
- Hardware packed in a solid carton box
- Roof and sidewall in a self-made PVC carry bag
- Tailor-made packing is available
