Stainless Steel Wedge Wire Laterals For Ion Exchange ISO Certification
Stainless Steel Wedge Wire Laterals For Ion Exchange ISO Certification
Stainless Steel Wedge Wire Laterals For Ion Exchange ISO Certification
Stainless Steel Wedge Wire Laterals For Ion Exchange ISO Certification
Specifications
Brand Name :
Lehler
Model Number :
WWL-008
Certification :
ISO9001:2015
Place of Origin :
Qingdao, China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100 pieces 1 work day
Delivery Time :
7 work days
Packaging Details :
Plywood Case for Exporting Package
Product :
Wedge Wire Laterals
Stainless Steel :
316L
Application :
Ion Exchange
Slot :
250 micron
Support Rod :
2.0x3.0mm
Profile Wire :
1.0x2.0mm
Type :
Horizontal
Hub :
8 hubs
Description

Wedge Wire Laterals / Stainless Steel Filter Nozzles for Ion Exchange

1. What is Filter Nozzles?

Wedge wire laterals is hub and lateral assemblies.

Typical configurations include both horizontal herring bone style and vertical secured round hub.

2.Specification of Wedge Wire Laterals?

Profile wire Support Rod
0.75*1.5mm 2*3mm
1.0*2.0mm 2*3mm
2.0*3.0mm 3*5mm
2.0*4.0mm 3*5mm
3.0*5.0mm 3*5mm


3.Details pictures of Wedge Wire Laterals:

Stainless Steel Wedge Wire Laterals For Ion Exchange ISO Certification

Stainless Steel Wedge Wire Laterals For Ion Exchange ISO CertificationStainless Steel Wedge Wire Laterals For Ion Exchange ISO Certification

Stainless Steel Wedge Wire Laterals For Ion Exchange ISO Certification

4. Material of Wedge Wire Laterals?

  • SUS304
  • SUS316L
  • SUS904L
  • Duplex 2205
  • Duplex 2507
  • Hastelloy
  • All dimentions can be customerized.
  • All accessaries can be sustomerized.

5. Advantages of Wedge Wire Laterals?

  • Good roundness body: Ovality deviation is within 0.03mm.
  • Uniform slots: slot opening deviation is within 0.015mm.
  • No jam and Easy to cleaning by backwash.
  • Long use time: Stainless steel material
  • Larger slot opening area.
  • Cost effectiveness.
