Stainless Steel Wedge Wire Screen Panels Curved Screen High Capacity / Efficiency
Stainless Steel Wedge Wire Screen Panels Curved Screen High Capacity / Efficiency
Stainless Steel Wedge Wire Screen Panels Curved Screen High Capacity / Efficiency
Stainless Steel Wedge Wire Screen Panels Curved Screen High Capacity / Efficiency
Specifications
Brand Name :
Lehler
Model Number :
SBS 1200
Certification :
ISO9001:2015
Place of Origin :
Qingdao, China
MOQ :
1 piece
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
7 work days
Packaging Details :
Plywood Case for Exporting Package
Price :
Negotiable
Name :
Sieve Bend Screen
Application :
farming
MOC :
SS316L
Profile wire :
1.0x2.0mm
Support rod :
2.0x3.0mm
Slot :
0.25mm
Description

Stainless Steel SUS316L Wedge Wire Sieve Bend Screen 1200X600mm

1. Wedge Wire Sieve Bend Screen Introduction:

Lehler Sieve Bend Screens is a pre-filter to improve the performance of the clarifier by drastically reducing the load.

A curved screen has greater capacity than a flat screen due to forces exerted as material flows against the curved surface.

Lehler sieve bend profile wire is 0.5 degree slanted, which is very efficient for filtration and separation.

Just like the first picture shows.

Stainless Steel Wedge Wire Screen Panels Curved Screen High Capacity / Efficiency

2.Specification of Lehler Sieve bend Screen?

Profile wire Support rod
0.76x1.5mm 2.0x3.0mm
1.5x2.5mm 2.0x3.0mm
2.0x3.0mm 3.0x5.0mm
2.0x4.0mm 3.0x5.0mm
2.5x3.0mm 3.0x5.0mm
3.0x5.0mm 3.0x5.0mm
3.0x6.0mm 5.0x8.0mm


3.Details pictures of Sieve bend Screen:

Stainless Steel Wedge Wire Screen Panels Curved Screen High Capacity / Efficiency

Stainless Steel Wedge Wire Screen Panels Curved Screen High Capacity / Efficiency

Stainless Steel Wedge Wire Screen Panels Curved Screen High Capacity / Efficiency

4. Application of Sieve bend Screen?

  • Used in static sieves, our sieve screens can be manufactured in flat, curved, and cylindrical styles based on your Application.

  • Used for dewatering. Aggregate and mining applications include coal, potash, taconite, sand or gravel. Chemical applications included fertilizer. Food applications include potatoes, other vegetables, sugar, cornstarch, and cereal.​

5. Advantages of Sieve bend Screen?

  • Non-clogging construction: The v-shaped wires and support rods is welded together by automatic resistance welding, which ensures a two- point contact between the particles and the slot,which minimizes clogging of near size product.
  • Strong construction: for most applications the wedge wire is self-supporting because of the welding at each intersection and can therefore withstand high pressure(Psi) and heavy loads.
  • Smooth Surface Filtration: very good smooth filtration surface, which reduce mechanical wear.
  • High-precision slot opening: Minimum Slot opening is 20 microns.
