Polymers Pneumatic Self Cleaning Strainer For Chemical Industry
Polymers Pneumatic Self Cleaning Strainer For Chemical Industry
Polymers Pneumatic Self Cleaning Strainer For Chemical Industry
Polymers Pneumatic Self Cleaning Strainer For Chemical Industry
Specifications
Brand Name :
Lehler
Model Number :
LFA-450
Certification :
ISO9001:2015
Place of Origin :
Qingdao, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1 set 10 work days
Delivery Time :
15 work days
Packaging Details :
Plywood Case for Exporting Package
Type :
Pneumatic Scraping
Inlet and outlet :
DN150
Filter Element :
wedge wire filter element
Drain outlet :
DN50
Filtration area :
0.82㎡
Application :
Polymers
Description

Polymers Pneumatic Automatic Self Cleaning Strainer For Fine Chemical Industry

Pneumatic scraping self-cleaning filter blends modern technology with simplicity to provide a versatile method of filtering your process fluids.

Working principle: liquid enters the filter body from inlet and flows through the filter element from inside to outside. Impurity is collected on the internal surface of the wedge wire element. The aircyliner drives scraper blade up and down to remove the impurity contiously. Cleaning takes place without interruption to flow by the rotation is deposited into the bottom of the filter body from where it can be periodically discharged automatically via the drain outlet.

Main technical specification:

Model Filtration surface area Scraper Filter housing Filter element Inlet / Outlet Drain outlet
LFA-D450 0.82㎡ PTFE SS316L SS316L DN150 DN150

Model Pneumatic cylinder: Design pressure Design temp. Power control box Drain Valve Surface treatment
LFA-D450 AirTAC 1.0Mpa 60-100℃ EX-proof Pneumatic ball valve Sand-blasting

All models of Pneumatic Automatic Self Cleaning Strainer:

Model Filtration area Outlet Inlet

Drain outlet
LFA-D219 0.2㎡ DN40 DN40 DN32
LFA-D273 0.43㎡ DN50 DN40 DN40
LFA-D450 0.82㎡ DN150 DN150 DN50

Polymers Pneumatic Self Cleaning Strainer For Chemical Industry

Application liquid:
wax, kerosene, monomer, polymer, water, citric acid, fermentation liquid, protein, soap, sorbitol, wet end additive, binder, Inks and Coatings, resin, rubber, ethanol, chocolate, candy, cooking oil, high temperature oil, juice, coolant, diesel oil...
Application industry:
Water treatment, Paper making, Petrochemical, Sanitary, Pharmaceutical, Inks and Coatings, Grease, Foof and beverage...
