Chemical Stability Food Grade SS304L 0.2mm Slot Wedge Wire Strainer For Water
Chemical Stability Food Grade SS304L 0.2mm Slot Wedge Wire Strainer For Water
Chemical Stability Food Grade SS304L 0.2mm Slot Wedge Wire Strainer For Water
Chemical Stability Food Grade SS304L 0.2mm Slot Wedge Wire Strainer For Water
Specifications
Brand Name :
STD Filter
Model Number :
STD WWF 022
Certification :
CE，ISO9001
Place of Origin :
Hebei,CN
MOQ :
1
Price :
$50-500 /pcs
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1 pcs per day
Delivery Time :
7 days or customized time
Packaging Details :
plastic in wooden package or standard export package
Color :
SS silver
shape :
Branch shape
Length :
customized
Type :
Filter Element
diameter :
customized
Slot size :
0.1-6.0 mm,customized to 0.02 mm
Usage :
liquid Filtration and division
Feature :
high resistance corrosion,easy to clean and backwashing
Material :
Stainless Steel
Application :
Liquid filter
Advantage :
Directly from factory
Filter rating :
99%
Width :
up to 1 meter ,customized.
Hole shape :
rectangle
Description

Stainless Steel 304 316 Wedge Wire Fractal Laterals Customized Shapes For Water Equipment


Materials:

The stainless steel wedge wire fractal laterals,also called header lateral assemblies, Header Lateral Distributors, hub radial laterals for water treatment. They are assemblies of horizontal herring bone style wedge wire screen laterals and vertical secured round hub. The screen lateral has inherent even pattern, which is made of stainless steel, hastelloy alloy steel and other alloy steels. The screen lateral has various slot size, wire size and diameters to suit common or customized applications.

Distributor and collector laterals promote even distribution while also avoiding flow/pressure concentrations. The non-plugging spider hub style design is ideal for accommodating disc head vessels. Made to your specification for size, open area and material, you can expect easy maintenance and exceptional long-term durability.

Contact us free for your special designed product!

Material SS304, SS304L, SS316, SS316L, SS321, 904, C276, 2205, 2207,Duplex, Hastelloy, etc
Normal Lateral Tube QTY (PCS) 4, 6, 8, 12,16, etc. According to request, actual flow rating, and application.
Lateral OD Range (mm) 25 to 80mm, customized
Normal Hub (mm) 108, 133, 219, Customized
Hub and lateral connector types Thread, Flange
Diameter Range(mm) According to the tank diameter. (Usually 200mm shorter than tank diameter)
Slot Range(mm) Normal slot 0.2, 0.25, 0.3, 0.35, 0.4mm.Slot according to request.
Wedge Wire(mm) 1x2 1.5x2 2x3
Support Rod (mm) 1.5x2.52x3 1.8x2.52x3 2x32x4
Note Customized According To Requirement

Characteristic:

1. Safety for food and drinking water.

2.Chemical stability

3.Resistance to corrosion and abrasion

4High strength and rigidity

5.Long work time

6.Easy to be washed and cleaned

7.Save time and money.

8.The number of branch is customized.

Chemical Stability Food Grade SS304L 0.2mm Slot Wedge Wire Strainer For WaterChemical Stability Food Grade SS304L 0.2mm Slot Wedge Wire Strainer For WaterChemical Stability Food Grade SS304L 0.2mm Slot Wedge Wire Strainer For Water

Packages:

Chemical Stability Food Grade SS304L 0.2mm Slot Wedge Wire Strainer For Water

The delivery:

Chemical Stability Food Grade SS304L 0.2mm Slot Wedge Wire Strainer For Water

Please Meet us on The http://www.wedgefilter.com,we will give you sincere sevice and an unbeatable price.
