Force Measuring Controller, With VFD display, High Speed Digit Transmission, With Alunimium Shell

BST106-F15 is suitable for 1-D Peak Value Force Measuring.

There are several kinds of application:

1. Positive&Negative Direction Real-time Force Value Display

2. Peak&Valley Value Detection / Display Holding / Printing

3. Setpoint DO Output and AO Transmission.

4. Real-time&High-speed Digit Transmission for sending Instantaneous Force Value or Instantaneous AD value with max. sampling frequency 800Hz to Force Value Analysis Computer via the digit communication port with max. baud rate 115.2kbps.

3 Optional Setpoint DO Output Modes: Force Limit DO Alarm Mode, Force Increment DO Output Mode, Force Decrement DO Output Mode and Force Section DO Output Mode.

Optional ‘Auto Enter Peak&Valley Value Detecting Process after Power-on’ function.

Technical Specification:

Detail Specification:

Executing Standard

1. CMC GB/T 7724-2008PRC National Standard.
2. OMIL R76: 2006International Recommendation.
3. Accuracy Grade: III.
4. Verification Accuracy: 0.02%.
5. Static Force Measuring Accuracy: 0.2%~0.5%.

Display

1. 6+10 Green VFD digital tubes for English character and digit display.
2. Force Value Display Range: -60,000~+60,000.
3. Force Capacity: Setting Range 1~60,000.
4. Scale Division: Optional 1, 2, 5, 10, 20, 50, 100, 200, 500.
5. Display Resolution: 1/60,000.
6. Force Value Unit: Optional kg, t, g, none.
7. Decimal Point: Optional 0, 0.0, 0.00, 0.000, 0.0000.
8. Display Refreshing Time: Setting Range 0.01~1.00s.

Keypad

1. 8-key English keypad.
2. Menu&Shortcut mode operation with key tone.
3. Loadcell Interface
4. Excitation Voltage/Max. Current: DC10V/250mA [8-350Ω loadcells].
5. Signal Input Range: 0~25mV.
6. Output Sensitivity of Loadcell: 1.0~2.5mV/V.
7. 24-bit ∑-△ADC with internal resolution 1/1,000,000.
8. Optional Sampling Frequency: 5, 100, 200, 400, 800Hz.
9. Zero Drift: ±0.1μV/℃ RTI (Relative to Input).
10. Gain Drift: ±5ppm/℃.
11. Non-linearity: 0.005%FS.

Switch&Analog Signal Interface

1. 3 Normally Open Switch Inputs [DI].
2. 5 Normally Open Relay Switch Outputs [DO]: AC250V/DC24V, 1A.
3. 1 Optional&Definable Analog Signal Output [AO]: 4~20mA, Non-linearity: 0.05%FS.
4. Digital Communication Interface
5. COM1: Fixed configuration RS232&RS485. Free to use one of them.
6. COM2: Optional RS232/RS485/RS422/Profibus-DP/Ethernet modules.
7. Connectable: Host IPC/PLC, LED Remote Display, Serial Printer and Wireless Module.

Report Print

1. The Force [Peak&Valley Value] Measuring Record can be printed automatically and manually.
2. Operating Specification
3. Optional Operating Voltage
4. Operating Voltage 1: DC24V±20%.
5. Operating Voltage 2: AC85~264V, 50/60Hz.
6. Operating Voltage 3: AC220V±15%, 50/60Hz.
7. Free to configure one of them.
8. Max. Power Consumption: 10W.

Outline Size

1. Model Panel-mounting: 164×82×188mm [W×H×D].
2. Model Explosion-proof: 340×390×205mm [W×H×D].
3. Panel Cut-out Size
4. Model Panel-mounting: 153×77mm [W×H].
5. Operating Temperature: -25℃ to +45℃.
6. Storage Temperature: -30℃ to +60℃.
7. Relative Humidity: Max. 85%RH.
8. Application Environment of Model Explosion-proof
9. Explosion gas environment: Zone 1&2.
10. Classes of explosion gas mixture: IIA, IIB.
11. Temperature grades of explosion gas mixture: T1~T6.
12. Ex-mark: Ex d IIB T6 Gb.

Protection Level

1. Front Panel of Model Panel-mounting: IP65.
2. Model Explosion-proof: IP65.

Weight

1. Model Panel-mounting: Approx. 1.6kg.
2. Model Explosion-proof: Approx. 19.2kg.

Operation Interface:

Demension:

Terminal:

Optional Type: Explosion-proof one
