Oxidation Resistant Square Welded Wire Mesh Smooth Surface For Machine Protection
Oxidation Resistant Square Welded Wire Mesh Smooth Surface For Machine Protection
Oxidation Resistant Square Welded Wire Mesh Smooth Surface For Machine Protection
Oxidation Resistant Square Welded Wire Mesh Smooth Surface For Machine Protection
Specifications
Brand Name :
Baodi
Model Number :
BD-WWMG
Place of Origin :
China
MOQ :
100 ROLLS
Payment Terms :
T/T, Western Union
Supply Ability :
1000 Rolls per month
Delivery Time :
15-40 days
Packaging Details :
Plastic film or water-proof paper
Price :
negotiated
Item :
Square Mesh Opening HDG Welded Wire Mesh
Surface Treatment :
Hot dipped galvanized
Material :
Low carbon iron wire
Aperture Size :
1/4" to 4"
Usage :
Construction wire mesh
Roll Length :
100'
Description

Square Mesh Opening HDG Welded Wire Mesh Used As Building Material

Square Mesh Opening HDG Welded Wire Mesh Characteristic

♦ Solid structure
♦ Wires resist movement
♦ Easy handling
♦ Extensive use
♦ High strength
♦ Square pattern
♦ Uniform mesh and smooth surface

♦ Savings in time, labour and money

Square HDG Welded Wire Mesh Introduction

1. The HDG Welded Wire Mesh is a metal wire screen, which is made up of low carbon iron wire or stainless steel wire. It is available in various sizes and shapes.

2. Welded wire mesh typically has larger openings than woven wire mesh.With the wire strands welded at each intersection, welded mesh is more capable of maintaining its shape when stressed.
3. It's available in various roll height: 2' / 3' / 3.28' / 4' / 5' / 6'

4. It could be packed in plastic film or waterproof paper.

NOTE: The welded wire mesh could be custom made by our factory.

Various Types of welded wire mesh

1. Electro galvanized welded wire mesh

2. Hot dipped galvanized welded wire mesh

3. PVC coated welded wire mesh

4. Stainless steel welded wire mesh

Usage of Square Mesh Opening Welded Mesh

♦ Welded wire mesh is widely used in agricultural, industrial, transportation, horticultural and food procuring sectors.

♦ It is also used in mines, gardening, machine protection and other decorations.

Specification of Welded Wire Mesh

Welded Wire Mesh

Mesh Opening

Wire Diameter<BWG>

In inch

In metric unit(mm)

1/4" x 1/4"

6.4mm x 6.4mm

22,23,24

3/8" x 3/8"

10.6mm x 10.6mm

19,20,21,22

1/2" x 1/2"

12.7mm x 12.7mm

16,17,18,19,20,21,22,23

5/8" x 5/8"

16mm x 16mm

18,19,20,21,

3/4" x 3/4"

19.1mm x 19.1mm

16,17,18,19,20,21

1" x 1/2"

25.4mm x 12.7mm

16,17,18,19,20,21

1-1/2" x 1-1/2"

38mm x 38mm

14,15,16,17,18,19

1" x 2"

25.4mm x 50.8mm

14,15,16

2" x 2"

50.8mm x 50.8mm

12,13,14,15,16

Galvanized Fencing Mesh

Mesh Opening

Wire Diameter<BWG>

In inch

In metric unit(mm)

2" x 3"

50mm x 75mm

2.0mm,2.5mm,1.65mm

3" x 3"

75mm x 756mm

2.67mm,2.41mm,2.11mm,1.83mm,1.65mm

2" x 4"

50mm x 100mm

2.11mm,2.5mm

4" x 4"

100mm x 100mm

2.0mm,2.5mm
PVC Coated Welded Mesh
Opening Wire Diameter<BWG>
In inch In metric unit(mm)
1/2" x 1/2" 12.7mm x 12.7mm 16,17,18,19,20,21
3/4" x 3/4" 19mm x 19mm 16,17,18,19,20,21
1" x 1" 25.4mm x 25.4mm

15,16,17,18,19,20

Technical Note:

♦ Standard roll length: 30m;width: 0.5m to 1.8m

♦ Special sizes available at request

♦ Packing: in waterproof paper in rolls. Custom packing available at request.
