5mm Steel Cnc Servo Motor Wire Straightening And Cutting Machine
5mm Steel Cnc Servo Motor Wire Straightening And Cutting Machine
Specifications
Brand Name :
Tianke
Model Number :
TK-CTZJ5
Place of Origin :
Hebei,China
MOQ :
One Set
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
15 sets/month
Delivery Time :
2 work days
Packaging Details :
Wooden box if one set ordered
Product Name :
CNC Steel Wire Cutting Machine
Wire Diameter :
2.5-5mm
Wire feeding :
Servo motor
Straightening Speed :
40 m / min
Cutting type :
Hydraulic cut-off
Type :
CNC fully automatic wire straightening and cutting machine
Motor :
2.2kw
Advantage :
Low noise,High quality machine parts,long time service life
Application :
metal wire (Low carbon steel wire, galvanized wire),stainless steel wire to straightening and cutting
Material :
Low Carbon Steel Wire,Aluminum wire,Galvanized Wire,Steel Wire,etc
Cutting Length :
Customized
Warranty :
12 months
Description

5mm Steel Wire CNC Steel Wire Cutting Machine Servo Motor

Introduction of CNC Steel Wire Cutting Machine

This machine is one kind of cnc wire straightening machine.The wire is feeding by servo motor.And wire cutting is by Hydraulic pump.So the speed of the machine is faster than the mechanical type machine.The machine is equipped with PLC control system.There are visual touch screen and buttons in the control panel.it is similar to a computer which is easy for the woker to learn how to operate the machine.

CNC Steel Wire Cutting Machine Feature

1. The straightening shaft is integrally cast. Lighter weight and less noise.

2. The straightening block is inlaid with the whole alloy, which is wear-resistant. It can be used for six to seven years.

3. The hydraulic cutting power is large, which can cut the iron wire with thicker diameter.

4. The iron wire is fed by servo motor, with fast feeding speed, stable performance and small error.

5. The machine is controlled by PLC control system.It is equipped with visual touch screen which is smilar to computer.This is easy for the woker to operate the machine.

Coil Wire Straightening And Cutting Machine Packaging and shipping

1. Packed in wooden case if one or two sets ordered. or customized.

2. FOB Tianjin or other China main port by sea.

3. FOB Beijing airport or China main airport by air.
