Condenser Evaporative Condenser Steel Nice Bundy Tube For Air Cooled Condenser Refrigerator

Description:

Color Bundy Tube /Single Wall Bundy Tube/Coating Bundy Tube
Diameter Size: 4,4.2,4.76,6.35,6.75,7.8,7.96,9.52,12.7
TK :0.5-1.0mm

Specifications:

Single wall bundy tube for condenser
Outer diameter: 4.0mm-12.0mm.
Wall thickness: 0.5mm-1.0mm.

Single wall bundy tube for Condenser .

Widely used in freezer,refrigerator

1. Material:be made of steel strap,low carbon;

2. Main use:widely used in refrigeration,freezer etc;

3. Outer diameter:4.00mm,4.76mm,6.00mm,6.35mm,8.00mm;

4. Wall thickness:0.50mm,0.60mm,0.65mm,0.70mm;

5. Packing as customer's request;

6. Also passed ISO9001 quality attestation system;

7. Competitive price among the same area.

8. Features: No stain, smooth surface, high intensity, good plasticity, strong corrosion resistance, small resistance.
9. Package : wooden boxes,iron pallets,iron boxes etc,we also can follow customer's own request

Bundy Tube /Brake Tube/ Coating Bundy Tube / PVF tube / Color Bundy Tube / Single Wall Bundy Tube
Plating:Copper, White&Yellow Zinc, Olive Green and PVF
Size:4.76, 6.35, 8, 9.5*0.7 mm,etc.
ISO9001,TS16949

The low carbon steel brake tube is supplied in single wall and double wall(Bundy Pipe). The products conform to ASTM A-254-91, A-512-91A and ASTM A214 and A513 in material and quality. Commonly sizes we supply to the client include 4.76mm×0.7 mm,6.35 mm×0.7 mm and 8 mm×0.7 mm.

Plating:Yellow Zinc,White Zinc,Copper and PVE. Package:in coils/cut-to-length Application:Hydraulic brake line tubing, brake tubing, brake pipes, fuel lines, transmission oil cooler lines, air conditioning tube, power steering, condenser, compressor, evaporator etc.

Standard ASTM A254
OD:4mm,4.76mm 6mm 6.35mm.7.94mm,8mm,12.76
WT:0.4-1.0MM
