304 Food Grade Stainless Steel Woven Wire Mesh 150 Micron For Conveyor Belts Eye Link
304 Food Grade Stainless Steel Woven Wire Mesh 150 Micron For Conveyor Belts Eye Link
304 Food Grade Stainless Steel Woven Wire Mesh 150 Micron For Conveyor Belts Eye Link
304 Food Grade Stainless Steel Woven Wire Mesh 150 Micron For Conveyor Belts Eye Link
304 Food Grade Stainless Steel Woven Wire Mesh 150 Micron For Conveyor Belts Eye Link
304 Food Grade Stainless Steel Woven Wire Mesh 150 Micron For Conveyor Belts Eye Link
Specifications
Brand Name :
Vinstar
Place of Origin :
Anping,China
MOQ :
10m
Price :
Negotiated
Supply Ability :
50-100 rolls/month
Delivery Time :
7-30 days
Packaging Details :
kraft paper and weaving bags
Material :
304
Wire Dia. :
0.41mm
Mesh :
150 mesh
Weaving :
Plain Weaving
Width :
1.8m
Length :
50m
Type :
Weave Wire Mesh
Technique :
Woven
Usage :
Filter
Sample :
Avaliable
Color :
Silvery
Description

304 food grade stainless steel 150 micron wire mesh used for conveyor belt / conveyor belts eye link

Material: 304,304L,316,316L, etc

Wire diameter: 0.025mm-1.800mm

Mesh size: 2mesh-2800mesh(0.02~10.9mm)

Producte description: Plain weave type square mesh hole shape both warp and weft diameter are the same in per linear inch precise mesh hole size for filtering mesh count per 1 to 635 mesh, MIN mesh hole size is 20 micron the dense the mesh,the fine the mesh,which is also called stainless steel wire cloth supper thin thickness Specially used for pharmaseutical and lab test sieve usually the size per roll is 1.02m/1.22m X30meter,or customized as per requirement

Roll width:0.914m,1.0m,1.22m,1.5m,1.8m,2.0m, any width available at request.

Roll length:30m or 50m,any length available at request.

Characteristics: Wear-resisting, Heat-resisting, Acid-resisting, Corrosion-resisting, Tear-resisting

Usage: Mainly used for Separation and Flitration, extensively used in petroleum, chemical industry, food industry, pharmaceutical industry, enviroment protection, mine, airspace, paper-making, electronic, metallurgy etc.

Mesh/Inch

Wire Diameter

Aperture

Open Area

Weight(LB) /100 Square Foot

Inch

MM

Inch

MM

1x1

.080

2.03

.920

23.37

84.6

41.1

2X2

.063

1.60

.437

11.10

76.4

51.2

3X3

.054

1.37

.279

7.09

70.1

56.7

4X4

.063

1.60

.187

4.75

56.0

104.8

4X4

.047

1.19

.203

5.16

65.9

57.6

5X5

.041

1.04

.159

4.04

63.2

54.9

6X6

.035

.89

.132

3.35

62.7

48.1

8X8

.028

.71

.097

2.46

60.2

41.1

10X10

.025

.64

.075

1.91

56.3

41.2

10X10

.020

.51

.080

2.03

64.0

26.1

12X12

.023

.584

.060

1.52

51.8

42.2

12X12

.020

.508

.063

1.60

57.2

31.6

14X14

.023

.584

.048

1.22

45.2

49.8

14X14

.020

.508

.051

1.30

51.0

37.2

16X16

.018

.457

.0445

1.13

50.7

34.5

18X18

.017

.432

.0386

.98

48.3

34.8

20X20

.020

.508

.0300

.76

36.0

55.2

20X20

.016

.406

.0340

.86

46.2

34.4

24X24

.014

.356

.0277

.70

44.2

31.8

30X30

.013

.330

.0203

.52

37.1

34.8

30X30

.012

.305

.0213

.54

40.8

29.4

30X30

.009

.229

.0243

.62

53.1

16.1

35X35

.011

.279

.0176

.45

37.9

29.0

40X40

.010

.254

.0150

.38

36.0

27.6

50X50

.009

.229

.0110

.28

30.3

28.4

50X50

.008

.203

.0120

.31

36.0

22.1

60X60

.0075

.191

.0092

.23

30.5

23.7

60X60

.007

.178

.0097

.25

33.9

20.4

70X70

.0065

.165

.0078

.20

29.8

20.8

80X80

.0065

.165

.0060

.15

23.0

23.2

80X80

.0055

.140

.0070

.18

31.4

16.9

90X90

.005

.127

.0061

.16

30.1

15.8

100X100

.0045

.114

.0055

.14

30.3

14.2

100X100

.004

.102

.0060

.15

36.0

11.0

100X100

.0035

.089

.0065

.17

42.3

8.3

110X110

.0040

.1016

.0051

.1295

30.7

12.4

120X120

.0037

.0940

.0064

.1168

30.7

11.6

150X150

.0026

.0660

.0041

.1041

37.4

7.1

160X160

.0025

.0635

.0038

.0965

36.4

5.94

180X180

.0023

.0584

.0033

.0838

34.7

6.7

200X200

.0021

.0533

.0029

.0737

33.6

6.2

250X250

.0016

.0406

.0024

.0610

36.0

4.4

270X270

.0016

.0406

.0021

.0533

32.2

4.7

300X300

.0051

.0381

.0018

.0457

29.7

3.04

325X325

.0014

.0356

.0017

.0432

30.0

4.40

400X400

.0010

.0254

.0015

.370

36.0

3.3

500X500

.0010

.0254

.0010

.0254

25.0

3.8

635X635

.0008

.0203

.0008

.0203

25.0

2.63

304 Food Grade Stainless Steel Woven Wire Mesh 150 Micron For Conveyor Belts Eye Link

304 Food Grade Stainless Steel Woven Wire Mesh 150 Micron For Conveyor Belts Eye Link
