110x110 Mesh Metal Woven Wire Mesh 30m Length Stainless Steel Mesh Bunnings
110x110 Mesh Metal Woven Wire Mesh 30m Length Stainless Steel Mesh Bunnings
Specifications
Brand Name :
Vinstar
Place of Origin :
Anping,China
MOQ :
10m
Price :
Negotiated
Supply Ability :
50-100 rolls/month
Delivery Time :
7-30 days
Packaging Details :
kraft paper and weaving bags
Material :
304
Wire Dia. :
0.09mm
Mesh :
110x110
Weaving :
Plain Weaving
Width :
1.22m
Length :
30m
Type :
Weave Wire Mesh
Technique :
Woven
Usage :
Filter
Sample :
Avaliable
Description

110x110 Mesh,0.09mm Wire Diameter, Plain Weaving For Stainless Steel Woven Wire Mesh

Normal mesh size:

Plain weave: 0.5X0.5mesh to 635X635 mesh;

Twill weave:20x20mesh to 400x400mesh;

Plain dutch weave:10X64mesh to 80X700mesh;

Twill dutch weave:20x250mesh to 400X2800mesh;

Reversed dutch weave: 48x10mesh to 720x150mesh.

Wire diameter:0.025mm-1.8mm.

Roll width:1m,1.22m, any width available at request.

Roll length:30m,any length available at request.

Features:

Corrosion resistance.

Anti-acid and alkali

Anti-high temperture.

Good filter performance.

Long using life

Applications:

In acid, alkali environment conditions sieving and filtering.

Petroleum industry as mud mesh,.

Chemical fiber industry as screen mesh.

Plating industry as acid cleaning mesh.

Mesh/Inch

Wire Diameter

Aperture

Open Area

Weight(LB) /100 Square Foot

Inch

MM

Inch

MM

1x1

.080

2.03

.920

23.37

84.6

41.1

2X2

.063

1.60

.437

11.10

76.4

51.2

3X3

.054

1.37

.279

7.09

70.1

56.7

4X4

.063

1.60

.187

4.75

56.0

104.8

4X4

.047

1.19

.203

5.16

65.9

57.6

5X5

.041

1.04

.159

4.04

63.2

54.9

6X6

.035

.89

.132

3.35

62.7

48.1

8X8

.028

.71

.097

2.46

60.2

41.1

10X10

.025

.64

.075

1.91

56.3

41.2

10X10

.020

.51

.080

2.03

64.0

26.1

12X12

.023

.584

.060

1.52

51.8

42.2

12X12

.020

.508

.063

1.60

57.2

31.6

14X14

.023

.584

.048

1.22

45.2

49.8

14X14

.020

.508

.051

1.30

51.0

37.2

16X16

.018

.457

.0445

1.13

50.7

34.5

18X18

.017

.432

.0386

.98

48.3

34.8

20X20

.020

.508

.0300

.76

36.0

55.2

20X20

.016

.406

.0340

.86

46.2

34.4

24X24

.014

.356

.0277

.70

44.2

31.8

30X30

.013

.330

.0203

.52

37.1

34.8

30X30

.012

.305

.0213

.54

40.8

29.4

30X30

.009

.229

.0243

.62

53.1

16.1

35X35

.011

.279

.0176

.45

37.9

29.0

40X40

.010

.254

.0150

.38

36.0

27.6

50X50

.009

.229

.0110

.28

30.3

28.4

50X50

.008

.203

.0120

.31

36.0

22.1

60X60

.0075

.191

.0092

.23

30.5

23.7

60X60

.007

.178

.0097

.25

33.9

20.4

70X70

.0065

.165

.0078

.20

29.8

20.8

80X80

.0065

.165

.0060

.15

23.0

23.2

80X80

.0055

.140

.0070

.18

31.4

16.9

90X90

.005

.127

.0061

.16

30.1

15.8

100X100

.0045

.114

.0055

.14

30.3

14.2

100X100

.004

.102

.0060

.15

36.0

11.0

100X100

.0035

.089

.0065

.17

42.3

8.3

110X110

.0040

.1016

.0051

.1295

30.7

12.4

120X120

.0037

.0940

.0064

.1168

30.7

11.6

150X150

.0026

.0660

.0041

.1041

37.4

7.1

160X160

.0025

.0635

.0038

.0965

36.4

5.94

180X180

.0023

.0584

.0033

.0838

34.7

6.7

200X200

.0021

.0533

.0029

.0737

33.6

6.2

250X250

.0016

.0406

.0024

.0610

36.0

4.4

270X270

.0016

.0406

.0021

.0533

32.2

4.7

300X300

.0051

.0381

.0018

.0457

29.7

3.04

325X325

.0014

.0356

.0017

.0432

30.0

4.40

400X400

.0010

.0254

.0015

.370

36.0

3.3

500X500

.0010

.0254

.0010

.0254

25.0

3.8

635X635

.0008

.0203

.0008

.0203

25.0

2.63
