3.7V95Ah High Voltage EV Battery Module For Electric Truck And Heavy Duty Truck
3.7V95Ah High Voltage EV Battery Module For Electric Truck And Heavy Duty Truck
3.7V95Ah High Voltage EV Battery Module For Electric Truck And Heavy Duty Truck
3.7V95Ah High Voltage EV Battery Module For Electric Truck And Heavy Duty Truck
Specifications
Brand Name :
wenergy
Model Number :
EV-8688190-3.65V95Ah
Certification :
CE/MSDS/UN38.3/
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1000 Set/Sets Per Month
Delivery Time :
25 working days
Packaging Details :
Wooden case
Nominal Voltage :
3.67V
Nominal Capacity :
95Ah
Max. Pulse Discharging Current :
3C
Max. Pulse charging Current :
2C
Cyclelife :
3000times
Application :
Electric heavy duty truck , Electric truck ,Electric Medium truck
Description

3.7V95Ah high voltage battery EV battery module module for E delivery truck and heavy duty truck

No. Item Specification
1 Nominal Capacity 95Ah(25±3℃, 100%DOD,0.5C)
2 Nominal Voltage 3.67V(5P1S)
3 Charge Ending Voltage 4.2V(5P1S)
4 Discharge Ending Voltage 0℃≤T(Temperature)≤55℃ 3.0V(5P1S)
-20℃≤T(Temperature)≤0℃ 2.4V(6P1S)
5 Standard Charging Method 25±2℃0.5C constant current charge to 4.2V(5P1S) , then constant voltage 4.2V (5P1S)charge till charged current declines to ≤ 0.05C
6 Max. Constant Charging Current 1C
7

Max. Pulse Charging Current

2C≤30S
8 Standard Discharging Current

25±2℃,0.5C constant current discharge to 3.0V(5P1S)
9 Max. Constant Discharging Current 1C
10 Max. Pulse Discharging Current 3C(≥50%SOC,≤30s)
11 Operating environment

Charging:0℃~55℃, max.90%RH

Discharging: -30℃~55℃, max.90%RH

SEPNi8688190P-17.5Ah/19Ah Module List

Name Parameter
Cell model SEPNi8688190P(NCM)
Configuration 4P1S 5P1S
Module rated voltage(V) 3.65
Module capacity(Ah) 70/76 87.5/95
Module Weight 1.31kg±0.05kg 1.61kg±0.05kg
Weight Energy Density 195Wh/kg 198Wh/kg
Application Electric Medium/Heavy-duty truck ,Electric Garbage/Refuse truck, electric Pick-up truck

Applications :

The battery module are widely used in electric commercial truck such as Electric Tipper truck ,electric delivery truck ,Electric Food truck,electric sannitation truck and other electric light/ heavy duty truck .

Electric commercial truck battery system list

Battery model Voltage Capacity Total Energy Application Battery cells Type
EV-335V265 335.8V 262.5Ah 88.14KWh electric food delivery van NCM
EV-394V262.5 394.2V 262.5Ah 103.4KWh Electri cutway van NCM
EV-394V350 394.2V 350Ah 137.9KWh Electric step van NCM
EV-394V560 394.2V 560Ah 220.7KWh Electric heavy duty truck NCM
EV-72300 72V 300Ah 21.6KWh Electric farm tractor NCM
EV-36081 360V 81Ah 29.1KWh Electric business bus NCM
EV-568.8V 162AH- 568.8V 162Ah 92.1KWh Electric Garbage truck NMC
EV-396V608Ah 396V 608Ah 241KWh Electric Medium truck NMC
