5400 Pixels Corn Grain Sorting Machine 384 Channels with High Capacity
5400 Pixels Corn Grain Sorting Machine 384 Channels with High Capacity
5400 Pixels Corn Grain Sorting Machine 384 Channels with High Capacity
5400 Pixels Corn Grain Sorting Machine 384 Channels with High Capacity
5400 Pixels Corn Grain Sorting Machine 384 Channels with High Capacity
5400 Pixels Corn Grain Sorting Machine 384 Channels with High Capacity
Specifications
Brand Name :
WENYAO
Model Number :
WYCS6-384
Certification :
CE & ISO9001
Place of Origin :
China
MOQ :
1 PCS
Price :
Negotiable price
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200PCS Per Month
Delivery Time :
15 to 20 working days
Packaging Details :
Plywood case package Packing size(L*W*H):2.70*1.72*2.05M
Function :
color sorting machine
Condition :
Brand New
Sorting accuracy(%) :
≥99.99
Warranty :
2 Years warranty
Color :
White ,according to customer's needs
After-sales service provided :
Engineers available to service machinery overseas,Field installation,commissioning and training,Overseas service center available,Field maintenance and repair service
Light Source :
LED
Application :
Rice processing,sorting,wheat,grain cleaning and separator
Voltage :
220V 50HZ
Whole Power :
3.1
Ejector :
Metal ejector
Feature :
Easy to Operate ,high sorting accuracy
Description

High Capacity CCD Camera Color Sorter Machine For Sorting Corn Grain Color Sorter


Parameters as below:

Main Parts Parameters/ brand Parts Advantage and warranty
Channels 64*6=384 1.High quality aluminum alloy 2.Anodic oxidation 3.Surface polishing treatment 4.Material Slipping steadily 5.wear-resisting,wearproof 6.The service life is long.
Pixel of camera 5400 1.High accuracy 5400 pixels 2.High perfomance with high resolution.warranty:2 years
CCD sensor Toshiba High Sensitivity and resolution warranty:2 years
Light source LED Lamps 1.Luminous evenly 2.The service life is long 3.The light is not weak for long time

Ejector Metal 1.High speed effect 1500times/second.2.Low air consumption 3.long time service.warranty:18 months.
Filter YSC/CKD 1.High filtration accuracy 2.High filtering speed 3.durable and long time service.
Screen Touch screen 1.Easy to operate with the man-machine interface 2.High sensitivity of the screen 3.The service life is long.4.Software update service program warranty:2 years
Hopper 304 stainless steel 1.Rust protection 2.Wear-resisting,wearproof
Package Plywood case 1.Stable structure no deformation 2.Easy to transport

Camera

leading in the industry

International well-known brand customized lens
Import high-end 4096PIXEL CCD sensor
High-speed of scanning
The highest resolution comes to 0.02 mm²

High-frequency Solenoid Valve

leading in China

High-quality high-frequency solenoid valve, with consistency of near zero error.

Service life more than 1 billion times.
Ultra high precision, leading in China

Intelligent Image Processing Algorithm

The combination of colors and shapes of

intelligent algorithm
Leading role in China.
Precise professional sorting solutions

Customized Lighting System

import purchasing

Advanced LED optical design system.
Various light sources are available to suit different materials.
Designated procurement of imported LED lamps,Higher stability, longer service life.
LED lighting system with thermal dissipation.

Data Transmission System

high-speed and stable

The COAX interface:
High anti-jamming, high transmission speed, high stability

Chip

innovative ultra high-speed processing

Based on SOC platform architecture;
Compared to DSP platform, the CPU improves 5 times, output processing improves 4 times, realizing the stability ,reliability and high-speed mass data processing.

Feed Trough

special technology

Application of high-quality 300mm ultra wide trough in China;

Special anodization treatment process ensures the required production in line with the international first-class level;

Cascading flat plate and narrow chute channel can be outfitted to sort a variety of material colors.

Human-Computer Interface

simple and easy to operate

More intelligent, easy operation, one button for professional sorting, remote debugging, remote diagnosis, remote software upgrading.

How does a color sorter work? The raw material enters the machine from the top hopper/storage hopper. Through the vibration of the vibrator device, the raw material slides down the channel accelerate down into the observation zone in the sorting cabinet and pass between the sensor and the background plate.

Our Strength:

1. With Over 14 years experiences.focus on sorter machine.

2.After-sales service guarantee: We have a professional after-sales service team, one-on-one customer service to help customers install and w.

3.We have service station, cooperate reseller in more than 100 countries.

4.Quality assurance of raw materials: The raw materials we purchase are certified qualified products.

5.Quality process assurance: We pass ISO quality management system, each process of production are under strictly standard.
6.System test: Our technical engineers check the product performance, to ensure that the factory products in full compliance with customer requirements


Color sorter work principle:

5400 Pixels Corn Grain Sorting Machine 384 Channels with High Capacity

Working principle CCD color sorter CCD digital camera to material is adopted signal acquisition.Analyze the collected signals, handling, comparison, to eliminate beyond the value of the material.
Color selection process as shown:

Color sorter at work,Feed hopper in the material under the action of vibrator is uniform distribution in each chute,The CCD signal of the whereabouts of the material in testing,If it is found that there are unqualified material or impurities in the material,The startup ejector to blow the defective goods in the hopper.(Above only for the working process of the diagram,The actual material shall prevail.)

Examples of color sorting:

5400 Pixels Corn Grain Sorting Machine 384 Channels with High Capacity

5400 Pixels Corn Grain Sorting Machine 384 Channels with High Capacity

From Customer's Site :

5400 Pixels Corn Grain Sorting Machine 384 Channels with High Capacity5400 Pixels Corn Grain Sorting Machine 384 Channels with High Capacity


Frequently Asked Questions:

1. How to install and use the machine?
We will supply the Installation instructions or videos and our engineers will train the operators.

2. How long about the guarantee period?

2 years. We supply lifelong software upgrade services for our customers.
3. Can you supply air compressor, air tank and air filters?
Yes, We can provide above equipments, Our standard offer includes color sorter machine with air compressor, air tank and filters.

4. How about after sales service?

Yes, By videos or by remote control or local service or engineers could go abroad when required.
5.Will you accept L/C as payment?
L/C ,T/T is OK.

6.Will you test machine before delivery ?

Yes , we will test carefully before delivey ,and save parameters in the machine

Packing And Delivery:

5400 Pixels Corn Grain Sorting Machine 384 Channels with High Capacity5400 Pixels Corn Grain Sorting Machine 384 Channels with High Capacity
