Reliable raw material epoxy resin liquid fast delivery stable products
Reliable raw material epoxy resin liquid fast delivery stable products
Reliable raw material epoxy resin liquid fast delivery stable products
Reliable raw material epoxy resin liquid fast delivery stable products
Reliable raw material epoxy resin liquid fast delivery stable products
Reliable raw material epoxy resin liquid fast delivery stable products
Specifications
Brand Name :
wenyou
Model Number :
8216F
Certification :
ISO9001, ISO14001, SGS, and UL
Place of Origin :
China
MOQ :
20kg/pail as sample
Price :
Negotiable
Payment Terms :
Normally L/C, T/T
Supply Ability :
Plenty of raw material in stock
Delivery Time :
7 -10 work days
Packaging Details :
20kg/pail, 220kg/barrel, 1200kg/tank
Classification :
Double Components Adhesives
Usage :
Dry - type Transformer
Application :
Electrical insulators for medium and high voltage applications
Appearance of epoxy resin :
Transparent viscous liquid
Appearance of hardener :
Light yellow transparent liquid
Viscosity at 25°C :
150 - 450mPa.s
Density at 25°C :
1.17 - 1.24g/cm3
Vapor Pressure at 25°C :
around 0.5Pa
Flash point :
around 140°C
Description :
Reliable raw material epoxy resin liquid fast delivery stable products
Description

Brief Introduction

Reliable Raw Material Epoxy Resin for Fast Delivery and Stability

LE-8216F is a modified saturated cyclic aliphatic epoxy resin system.

LH-8216F is a modified weather-resistant anhydride hardener.

Applications

  • Designed for electrical insulation in medium and high voltage applications.
  • Suitable for dry-type transformers, 10-66 kV current transformers, voltage transformers, and other related components.

Processing Methods

  • Conventional Gravity Casting Process under vacuum.
  • The production process can be customized to align with the client's existing manufacturing methods.

Properties

  • This two-component saturated cyclic epoxy resin system is free of pre-mixed fillers and remains liquid at room temperature.
  • Offers low curing shrinkage, excellent dimensional stability, outstanding processing characteristics, and superior mechanical and electrical performance.

Formulation

Epoxy resin LE-8216F 100 pbw
Hardener LH-8216F 100 pbw
Filler Silica Powder 300-360 pbw
Color paste LC series * Appropriate

Package Image

Reliable raw material epoxy resin liquid fast delivery stable products

Example application image

Reliable raw material epoxy resin liquid fast delivery stable products
