MAIN FUNCTIONS

The machine is designed and made to high quality and safety standard, stable and consistency high printing quality maximize the production efficiency.

The main motor, suction blower is adopted frequency control, which is variable by speed.

Folder Gluer Inline Control, the main function can be adjusted by data input or order management system.

High speed inline top flexo print case maker with down folding provides a complete carton boxes producing solutions.

Can easy match with Pre-feeder or Automatic Strapping Machine.

Max. Speed: 350sheets/min.

All computerized control with memory of 1000 orders.

Ink shortage alarm device with auto feeding.

All unit adopt oil balance control system by separation device. Fine fault alarm prompts. Electrical box air conditioning constant temperature system.

Units are auto Zero reset.

Breakdown and alarm malfunction system, Main Motor With Start Delay Protection Function. If Not All the Units Locked Well, the Main Motor Will Not Work.

FEEDING UNIT

The Central Console is adopted to Windows system for easily operating.Feeding gaps adjustment are computerized control with screen display

Auto zero-set for feeding position to reduce adjusting time.

Servo Control Non-crush Feeding System as optional.

Feeding volume is frequency control and can be adjusted according to cardboard size.

Main motor,suction blower and dust suction are frequency control.

The speed can be adjust freely with synchronous belt drive.

For example as 1224 model Lead Edge Feeder equipped with 4 axis for transmission.

The extension dust removing system with 4 blower fans, 2 brushes, and anti-static system optional.

The permanent magnet fan frequency conversion controls the vacuum air flow and pressure, which can adapt to different cardboard specifications, save energy and reduce noise

PRINTING UNIT

Vacuum Transfer System can adjust Air-Volume automatically according to cardboard size.

The clearance of each pressure wheel is adjusted by computer setting.

Reel hanging plate, ratchet locking device to make sure hanging plate alignment is more accurate.

The anilox roller can be automatically lifted and lowered sequentially with the paper feeding system (the doctor blade system can be configured as optional).

Ink shortage will automatically alarm and stop feeding paper to avoid damage to the rubber roller and anilox roller.


Printing Register is by servo control,Ratchet can be adjusted quickly.

Cardboard transmission situation can be checked by the Central computer

Auto zero- set for printing position.

SLOTTING UNIT

8 Shaft Transmissions, Pre-creasing, Big and Small Creasing, Single Shaft Slotting or Pre-creasing, Creasing, Dual Slotting is Optional.

Linear Guiding structure combined with Ball Screw for Transverse adjustment to make sure accurate knife fitting, stable movement.

Transverse, Box Height, Gaps adopts computerized or motorized adjusted. Slotting Register is Servo Control, more precision.

Elastic Corner Cutter Structure to suitable for different thickness cardboard.

Frequency adjust the slotting knife which is more accuracy and stable.

The lower corner cutter can be rotated to protect the upper corner cutter, and ensure the stitching flap can be cut off.

DIE CUTTING UNIT

Independent Frequency Motor for Line Speed Compensation

Servo independent drive is optional

Die-cutting Register servo control.

Line speed compensation frequency control.

With automatic grinding device

Auto zero- set for die cutting position.
