Specifications
Brand Name :
Cansec Wireless
Model Number :
LRW32NA-C
Place of Origin :
Beijing
MOQ :
1000
Price :
USD5.5$ Per Piece
Payment Terms :
T/T
Supply Ability :
20000000 units per year
Delivery Time :
5-8 weeks
Packaging Details :
Three layers of protection anti-static bag & moisture-proof & cardboard box ensure transportation safety
Chipset :
ST-STM32WLE
Application :
IoT
Size :
13*13*2.8mm
Operating Temperature :
re: -20 - 70℃
Operating Voltage :
2.5-3.7V
TX Power :
20dBm
RX Sensitivity :
-140dBm
Sleep Current Consumption :
2μA
Description

ST STM32WLE IoT LoRa Gateway Module 20dBm Lora Long Range Module

Iot Industrial Solution Small Size Wearable Cansec Wireless Receiver Module St-Stm32Wle Iot Lora Gateway Module

Parameter
Min
Typ
Max
Unit
Operating Voltage
2.5
3.3
3.7
V
Operating Temperature
-20
-
70
°C
Current
Consumption
Rest
-
2
uA
Receive
-
12.5
mA
Transmit Mode
-
120
mA
TX Power
-
20
dBm
RX Sensitivity
-
-140
dBm

Iot Industrial Solution Small Size Wearable Cansec Wireless Receiver Module St-Stm32Wle Iot Lora Gateway Module

Feature

- LoRa spread spectrum modulation technology

- Receive sensitivity as low as -141dBm

- Excellent resistance to blocking

Description

1. The LRW32 long-range wireless and ultra-low-power devices embed a powerful and ultra-low-power radio compliant LPWAN radio solution: LoRa® (only available in STM32WLE5xx), (G)FSK, (G)MSK, and BPSK.
2. The devices embed high-speed memories (Flash memory up to 256 Kbytes, SRAM up to 64 Kbytes), and an extensive range of enhanced I/Os and peripherals.
3. The devices also embed several protection mechanisms for embedded Flash memory and SRAM: readout protection, write protection and proprietary code readout protection.
4. These devices offer a 12-bit ADC, a 12-bit DAC low-power sample-and-hold, two ultra-low-power comparators associated with a high-accuracy reference voltage generator.
Features
LoRa ™ spread spectrum modulation technology
Receive sensitivity as low as -141 dBm
Excellent resistance to blocking
Supports preamble detection
Supports half-duplex SPI communication
Programmable bit rate up to 300Kbps
Supports FSK, GFSK, MSK, GMSK, LoRa ™ and OOK modulation modes
Supports automatic RF signal detection, CAD mode and ultra high speed AFC
Packets with CRC, up to 256 bytes
Small package with double volume stamps
