TA3235SSA-C IoT Wifi Module
TA3235SSA-C IoT Wifi Module
TA3235SSA-C IoT Wifi Module
TA3235SSA-C IoT Wifi Module
Specifications
Brand Name :
Cansec Wireless
Model Number :
TA3235SA-C
Place of Origin :
Beijing
MOQ :
100
Price :
USD 7.5$ per piece
Payment Terms :
T/T
Supply Ability :
2000000 pieces per year
Delivery Time :
3~6 weeks
Packaging Details :
Box for 1000 pieces Package size: 40*34*20 cm Gross weight: 5.000 kg
size :
18.2*33*2.8mm
TX Power :
16.5dBm
RX sensitivity :
-95dBm
TX current 2.4GHz :
380mA
RX current 2.4GHz :
77mA
Standby current :
1uA
Antenna type :
Chip Antenna
Chipset :
CC3235
TX current 5G :
470mA
RX Current 5GHz :
87mA
Description

AT Command Available Smart Home Dual Mode Wifi Solutions Module Cansec TA3235SSA-C Ti CC3235 Intelligent Wifi Switch Module

Parameter
Min
Typ
Max
Unit
Operating Voltage
2.5
3.3
3.6
V
Operating Temperature
-20
-
+70
℃
Current
Consumption
Sleep Mode
2.4G
-
-
5.2
uA
5G
-
-
5.2
uA
Receive mode
(MCU active)
2.4G
-
-
77
mA
5G
-
-
87
mA
Transmit Mode(CW)
( at +18 dBm ,+3.3V)
2.4G
-
-
380
mA
5G
-
470
mA
TX Power(CW)
2.4G
-
16.5
18
dBm
5G
-
14.5
18
dBm
RX Sensitivity
2.4G (at 1 DSSS)
-
-
-94.5
dBm
5G (at 6 OFDM)
-
-
-89
dBm

AT Command Available Smart Home Dual Mode Wifi Solutions Module Cansec TA3235SSA-C Ti CC3235 Intelligent Wifi Switch Module

The TA3235 is a WIFI module. The integrated hardware solution comprises the CC3235S/CC3235SF Wi-Fi wireless MCU. Customers may reuse the reference design to design their own Board. The software and hardware design resources reduce engineering efforts, shorten time to market, and help developers and customers release their products with cloud connectivity features faster.

TA3235SSA-C IoT Wifi Module

TA3235SSA-C IoT Wifi Module

TA3235SSA-C IoT Wifi Module

TA3235SSA-C IoT Wifi ModuleTA3235SSA-C IoT Wifi Module

TA3235SSA-C IoT Wifi Module

TA3235SSA-C IoT Wifi ModuleTA3235SSA-C IoT Wifi ModuleTA3235SSA-C IoT Wifi ModuleTA3235SSA-C IoT Wifi Module

TA3235SSA-C IoT Wifi Module

FAQ

Q1: Are you a factory or trade company?
A1: We are a professional factory with 25 years experience.
Q2: Can you accept OEM/ODM?
A2: Sure, we have rich OEM&ODM experience.
Q3: Do you have quality assurance?
A3; Each of our products has undergone quality testing and has two years of free after-sales service.

A device that is not a member of a mesh network is referred to as an unprovisioned device. A device that is a member of a mesh network is known as a node. Devices are added to a mesh network by a Provisioner. Nodes in a mesh network share network keys that enable them to receive and to relay messages from other nodes in their network or subnet. Network keys are used to secure and authenticate messages at the network layer. Unprovisioned devices cannot receive messages because they do not have the network key to recover the message.

Bluetooth Products

The Bluetooth SIG defines a Bluetooth product as any product containing an implementation of Bluetooth wireless technology. Bluetooth products are classified as:

  • Bluetooth End Product

  • Bluetooth Host Subsystem Product

  • Bluetooth Controller Subsystem Product

  • Bluetooth Profile Subsystem Product

  • Bluetooth Component Product

  • Bluetooth Development Tool

  • Bluetooth Test Equipment

The Communications Toolbox Library for the Bluetooth Protocol provides features enabling you to model Bluetooth Host and Controller Subsystem Products fully compliant Bluetooth links with the low energy (LE) core configuration.
