Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector
Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector
Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector
Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector
Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector
Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector
Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector
Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector
Specifications
Brand Name :
Cansec Wireless
Model Number :
LRW32BH-UA/HA-C
Place of Origin :
Beijing
MOQ :
1000
Price :
USD 4.90$ per piece
Payment Terms :
T/T
Supply Ability :
20000000 units per year
Delivery Time :
5-8 weeks
Packaging Details :
Three layers of protection anti-static bag & moisture-proof & cardboard box ensure transportation safety
Chipset :
ASR6501
Application :
IoT
Size :
16*23*2.8mm
Operating Temperature :
-20 - 70℃
Operating Voltage :
1.8-3.7V
TX Power :
21dBm
RX Sensitivity :
-148dBm
Sleep Current Consumption :
3μA
Frequency :
434, 868, 915 MHz
name :
Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector
Description

Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector

IoT Modul Cansec 20dBm 915Mhz LoRawan LRW32 Wireless Module Transmission LoRa With Ipex Connector

Parameter
Min
Typ
Max
Unit
Operating Voltage
1.8
3.3
3.7
V
Operating Temperature
-20
-
+70
℃
Current
Consumption
Sleep Mode(Without RF Config Retention, with RTC)
-
3
4
uA
Receive mode
-
12
-
mA
Transmit Mode (@+20dBm, Carrier)
-
120
-
mA
TX Power (For Carrier)
-
20
21
dBm
RX Sensitivity (For Lora Modulation)
-
-
-140
dBm
Distance
2
Km

IoT Modul Cansec 20dBm 915Mhz LoRawan LRW32ASR6501 Wireless Module Transmission LoRa With Ipex Connector

LRW2020UA-A module is designed based on SX1262 and MCU which is a general LoRa Wireless Communication Chipset.The module with an AT instructions firmware, easy to use, reduce the development process of personnel.

Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector

Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector

Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector

Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector

Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector

Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector

Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector
Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector
Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector
Wireless Transmission 434mhz Lora Wifi Module With Ipex Connector
