Mini H 265 Dvr Digital Video Recorder 5 IN 1 Real Time 2 Megapixel Recording
Mini H 265 Dvr Digital Video Recorder 5 IN 1 Real Time 2 Megapixel Recording
Mini H 265 Dvr Digital Video Recorder 5 IN 1 Real Time 2 Megapixel Recording
Mini H 265 Dvr Digital Video Recorder 5 IN 1 Real Time 2 Megapixel Recording
Specifications
Brand Name :
WINBO
Model Number :
SAV-TVR6104LT-AM
Certification :
CE,ROHS
Place of Origin :
CHINA
MOQ :
10PCS
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, Western Union, T/T, MoneyGram,Paypal
Supply Ability :
10000PCS Per Month
Delivery Time :
5-8 Working Days for Sample Order.
Packaging Details :
Neutral Factory Box
Keywords :
Smart 4ch DVR
Operation System :
Embedded Linux
Resolution :
2MP 1080p
Hardisk :
1pcs HDD
Playback :
4CH
Meterial :
Metal
Compression :
H.265/H.264
Demenision :
215*215*50mm
Protocol :
Onvif 2.6
Description

Winbo H.265 Full HD 1080P 4CH 5 IN 1 Real time TVI DVR Mini DVR

Features

  • 4CH Smart DVR
  • P2P Service,mobile phone message
  • Support perimeter intrusion detectiont;
  • ONVIF 2.6
  • Up to 2Megapixel recording resolution;
  • 1pcs HDD, Support 3G WIFI

Specifications

Item 4CH Smart DVR
Model SAV-TVR6104LT-AM
P2P Function Using Device ID and password to login www.vssweb.net
Cloud storage Realize remote monitoring, playback and control like IE Web login.
LCD screen on Front panel No need any network, IP setting, easy for end user to use network function.
Operation system Embedded LINUX
Pentaplex function Live monitoring, recording, playback, backup & remote access
Control Mode Front panel, USB mouse, IR remote control, Network
IP Camera Input 4CH/8CH/16CH BNC
Decoding Capability 16CH 1080P@30FPS
Support Protocol ONVIF,Videopark
Standard PAL (625line, 50f/s) NTSC (525line, 60f/s)
Output 1 CVBS, BNC (1.0Vp-p,75 ohms)
1 HDMI, 1.3a
1VGA,1920u00d71080,1440u00d7900,1280u00d71024,1024u00d7768,800u00d7600 Resolution
Output 1CH,BNC(Line in,2Vpp,1Kohms)
Two-way Talk 1ch. Standalone
IP Resolution Main stream: Up to 3264x2448 Auxiliary stream:D1
Resolution 1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Frame 1~30fps
Tour Display Support
Working Status Display LCD,blue backlight(working temperature,recording status,error code etc.)
Privacy Masking Four zones for privacy masking for each channel
Video Compression MPEG-4/H.264(High Profile @ Level4.2uff09
Audio Compression G.711A
Image Encoding Adjustable encoding quality, variable code stream/fixed code stream
Dual Stream Support
Recording Mode Manual, auto, motion detection, stop
Time Bar Support
Trigger Events Recording, PTZ, Tour,Email
Motion Detection 396(22*18),Sensitivity: 1~6 (level 6 is highest)
Capture JPEG capture
Alarm Input 16ch.
Alarm Output 3ch.NO,NC
Max Playback 16CH
Backup Mode USB,HDD,Network Backup
Ethernet 2 RJ45 10M/100M/1000M self-adaptive Ethernet interface
Network Protocol TCP/IP, UDP, HTTP, RTP/RTSP
Network Functions DHCP, PPPOE, DDNS,SMTP,SNTP,FTP,UPnP,P2P,3G
Remote Operation Monitoring,PTZ control,playback,system setting,file download,log information
Smart Phone iPhone,iPad,Android,Blackberry,Windows Mobile
HDD Management Hard disk hibernation technology, HDD faulty alarm&raid
USB Interface 2 USB 2.0 ports
RS485 Standard 485, half duplex,PTZ control
Power Supply DC12V/3.3A
Power Consumption 110V~220V±10%, 47Hz～63Hz
Working Environment 1-10u2103~uff0b55u2103 / 10%uff0d90%RH
Dimension 215mm*215mm*50mm
Weight 7Kg (without HDD)
Installation Desk type
