High Efficient Hydraulic Offshore Marine Spooling Device Winch For Ship
High Efficient Hydraulic Offshore Marine Spooling Device Winch For Ship
High Efficient Hydraulic Offshore Marine Spooling Device Winch For Ship
High Efficient Hydraulic Offshore Marine Spooling Device Winch For Ship
High Efficient Hydraulic Offshore Marine Spooling Device Winch For Ship
High Efficient Hydraulic Offshore Marine Spooling Device Winch For Ship
High Efficient Hydraulic Offshore Marine Spooling Device Winch For Ship
High Efficient Hydraulic Offshore Marine Spooling Device Winch For Ship
Specifications
Place of Origin :
Hebei，China
Brand Name :
LBS
MOQ :
1 set
Packaging Details :
Export standard wooden case
Delivery Time :
30 to 40 working days, depends on order amount and specification
Payment Terms :
L/C, T/T
Supply Ability :
500 Pieces/Sets Per Month
Price :
Negotiation
Model Number :
Custom design
Main Port :
Tianjin China
Groove Type :
LBS Groove Or Helical Groove
Power Source :
Electric or hydraulic
Sling Type :
Wire Rope Or Cable
Braking System :
Mechanical Brake
Application :
ship...
Certification :
DNV, ABS, GL, LR, BV, CCS, RINA, NK,
Description

High Efficient Hydraulic Offshore Marine Spooling Device Winch For Ship

Product specification: Custom-made ( according to the customers' demand )

product name :electric mooring winch
Another name: marine winch, boat pulling winch ,offshore platfrom tower winch ,ship winch , wire rope winch,crane winch ,electric winch ,hydraulic winch
Drum type: Single and Multi-drum Type
Usage :marine ,boat, ship ,windlass,offshore
- Anchor Chain Size:15-100mm
- Mooring Winches:up to 200T Brake Holding
- With drag brake system
- Configuration: horizontal arrangement
- Rope speed: complying with working condition
-design :LBS groove drum that have more advantage above the rope of 6 layer
product parameter:

Model

Drum Load

(KN)

Nominal Speed

(m/min)

Holding Load

(KN)

 Dia. of Rope Capacity of Rope
LBSMO-001 30 15 90 15 150
LBSMO-002 40 15 120 19 150
LBSMO-003 50 15 150 20 180
LBSMO-004 75 15 220 26 180
LBSMO-005 80 15 240 28 200
LBSMO-006 100 15 300 28 200
LBSMO-007 125 15 310 30 200
BLSMO-008 150 15 450 32 250
LBSMO-009 160 15 470 34 250
LBSMO-010 180 9.5 580 40 250
LBSMO-011 250 9.6 730 40 250
LBSMO-012 310 7.8 940 50 250
Product structure:
1. The winches with spooling device can realize automatic rope arrangement.
2. The utility model is composed of six parts: power output part, gearbox, clutch, groove sleeve part, rope supporting part and base.
3.Winch spooling device (rope arranging device) adopts the principle of double screw to drive the rope wheel to move back and forth,
4. Automatic rope-arrangement transmission principle: winch drum - transmission - groove sleeve rotation - rope wheel reciprocating movement.
5. Do not need to change any part of the winch during installation, just installed in the outer gear winch motor side
6.Special LBS design can make your working even efficency to extend the rope and drum life.
Product application:
The winch is widely used in boat, port, workshop, warehouse, construction and many kinds producing-line, so is necessary equipment for lifting goods, raising labor efficiency, improving working conditions.

Product Features:
1. Compact structure and reasonable design
2. Keep the wire rope's tensioning tight for winches & cranes.
3. The spooling machine can supply a back force on the rope to keep the rope a tensioning force.The spooling machine and its HPU are removeable.

Product advantage:
1. Top quality with competitive price.
3. Safe and reliable function.
4. Highly efficient, constant operating torque motor.
5. Smooth running over the entire speed range.
6. Mechanical transmission device, easy to use, safe and reliable.

Company profile​:
Our factory mainly in the service of hoisting machinery, Marine machinery, petroleum machinery, hydraulic machinery, engineering machinery and other industries, the main products are oil drilling rig, workover rig, drifting machine, trailermounted pumping unit winch (The main drum is used LBS grooved drum) and oil equipment accessories.We have designed for many of the company and award a big praise from the customer.
