Integral Type LBS Groove Drum Winch For Offshore PlatformTower Crane
Integral Type LBS Groove Drum Winch For Offshore PlatformTower Crane
Integral Type LBS Groove Drum Winch For Offshore PlatformTower Crane
Integral Type LBS Groove Drum Winch For Offshore PlatformTower Crane
Integral Type LBS Groove Drum Winch For Offshore PlatformTower Crane
Integral Type LBS Groove Drum Winch For Offshore PlatformTower Crane
Integral Type LBS Groove Drum Winch For Offshore PlatformTower Crane
Integral Type LBS Groove Drum Winch For Offshore PlatformTower Crane
Specifications
Place of Origin :
Hebei，China
Brand Name :
LBS
MOQ :
1 set
Packaging Details :
Export standard wooden case
Delivery Time :
30 to 40 working days, depends on order amount and specification
Payment Terms :
L/C, T/T
Supply Ability :
500 Pieces/Sets Per Month
Price :
Negotiation
Port :
Tianjin China
Power Source :
Hydraulic System
Wire Diameter :
3 MM~190 MM
Rope Capacity :
100m~10000m
Product Condition :
Fully Machined
Grooving Type :
LBS Groove
Certification :
DNV, ABS, GL, LR, BV, CCS, RINA, NK,
Description

Product structure:
Product name: Offshore PlatformTower Crane
other name :hydraulic boat winch or anchor winch/windlass
Rope speed :0~200 m/min
Capacity:500~6000KGS
Groove type :LBS groove drum or as requirement
packing :wooden case
Power:hydraulic
Parameter:can be design as requirment
Our design advantage: We are LBS groove patent factory award by goverment.LBS design can make the winch work more effective than other design .As the rope in LBS groove would on and off the drum in a unifromed ways to provent the layer crushed or pinched by the up layer .It is more obvious in multi-layer .

Techinal parameter: can be design as customer

Model Rated load
(KN)		 Rated Speed
(m/min)		 Rope Capacity(m) Rope Dia(mm) Motor Power (kw) Dimension(mm) Weight(KG)
JK0.5 5 22 190 7.7 Y100L-4 3 620*701*417 200
JK1 10 22 100 9.3 Y112M-4 4 620*701*417 300
JZ1.6 16 24 150 12.5 G132S-4 5.5 945*996*570 500
JZ2 20 24 150 13 G132M-4 7.5 945*996*570 550
JZ3.2 32 25 290 15.5 G180L-6 15 1325*1335*840 1011
JZ3.2B 32 30 250 15.5 JZ200L-6 22 1900*1738*985 1500
JZ5 50 30 300 21.5 JZ225M-6 30 1900*1620*985 2050
JZ5B 50 25 210 21.5 LBSM-8 22 2250*2500*1300 2264
JZ8 80 25 160 26 LBS280S-8 45 1533*1985*1045 3000
JZ10 100 30 300 30 LBS315S-8 55 2250*2500*1300 5100

Product specification:

Custom-made (according to actual )

Ours services:

1. After-sales Service Provided: Engineers available to service machinery overseas

2. The warranty is one year

3. Top quality with competitive price

Company profile:

Our factory mainly in the service of hoisting machinery, Marine machinery, petroleum machinery, hydraulic machinery, engineering machinery and other industries, the main products are oil drilling rig, workover rig, drifting machine, trailermounted pumping unit winch (The main drum is used LBS grooved drum) and oil equipment accessories

Advantage and main feature

1. Top quality with competitive price.

2. Widely used in factory, mining, shipyard or double beam cranes.

3. Compact structure and reasonable design.

4. Easy to install, operate and maintenance.

5. Low noise and good working condition.

6. Safe and reliable function.
