Marine Rack And Pinion Steering Gear Rudder Blades For Deck Equipment
Marine Rack And Pinion Steering Gear Rudder Blades For Deck Equipment
Specifications
Brand Name :
Deyuan
Model Number :
DY080104
Certification :
CCS,ABS,DNV,BV,RINA ..
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20 sets/month
Delivery Time :
Within 20 to 30 days, According to customers's order
Packaging Details :
Export packing
Type :
Marine Steering Gear
Power Source :
Hydraulic
Max working torque :
As requirements
Max. mech. rudder angle :
± 45 degree
Rudder stock Diameter :
As requirements
Class Approval :
CCS,ABS,DNV,BV,RINA ..
Description

Marine Rack And Pinion Steering Gear Rudder Blades For Deck Equipment

Marin advantages:

1. Electro-hydraulic control.
2. Compact design.
3. Suitable for normal rudder blades.
4. Pumps with variable displacement or constant delivery.
5. One-piece tiller for standard or keyless fit of rudder stock.
6. pump units mounted on and completely piped with the cylinders.


Specification:

Suitable for:


Containers, tankers, ferries, General cargo ships, passage ships, Dredgers and any other vessels that need more steering torque.

(kn.m)
Nominal Torque

Turning
Angle
(°)

Turning time(s)

Rated power
(kw)

hydraulic steering gear Dimension (mm)

A

B

C

D

F

G

DY63

35

28s/65°

5.5

2470

2320

505

350

380

694.5

DY100

35

28s/65°

7.5

2718

2500

505

400

420

704.5

DY160

35

28s/65°

11

2996

2740

505

450

420

704.5

DY200

35

28s/65°

15

3304

3020

505

500

550

726.5

DY250

35

28s/65°

15

3630

3160

505

550

550

726.5

DY320

35

28s/65°

18.5

3938

3400

505

600

550

726.5

DY400

35

28s/65°

18.5

3914

3600

560

570

600

950

DY450

35

28s/65°

18.5

4000

3600

560

570

600

950

DY500

35

28s/65°

18.5

4000

3600

560

570

600

950



Quality Control:

Product Range: We specialized in majority of marine equipments& technique solution.

Product Design: With strong engineer team, for all marine products, we support design, manufacture, install etc, according to your requirements. All products strictly conform to your confirmation.

Product Process: Most of products are finished in our manufacture bases, thus quality and delivery time could keep best and , also avoid some details mistake

Product Inspection: We support factory inspection and inspection/certification.


Certificates:

- Material certificates by a classification society
- Inspection protocol
- Inspection reports tank testing
- NDT reports
- Official certificates for accessories and other equipment


Advantages of our factory:

1. Control the product quality from the source
2.The main mechanical stress components should pass flaw detection to ensure the quality.
3. Adopt domestic famous brand electric device
4. Fully equipped with accessories
5. Easy installation and operation
6. Provide professional customization service
7. Reasonable price and good after-sale service
8. Manufacture according to client's rquirements
