CSP Type 167Kva Pole Mounted Transformer Distribution Single Phase 4160V Oil Immersed ANSI IEEE CSA Standard

Single-phase cylinders are usually mounted directly on wooden or concrete poles for multi-scenario applications such as residential overhead distribution loads and light commercial loads, and are usually divided into conventional and CSP types

WINLEY's pole mounted transformer is designed and tested in accordance with standards including ANSI/CSA, IEEE c.57, and IEC60076 as applicable.

Pole Mounted Transformer Main data

CSP transformers and conventional transformers differ in several important ways

1. Efficiency
CSP transformers can achieve efficiencies of up to 99%, while conventional transformers typically reach around 95%. This higher efficiency translates to reduced energy losses.
2. Size and Weight
CSP transformers are significantly smaller and lighter than conventional transformers, making them easier to install and integrate into various environments.
3. Power Density
CSP transformers exhibit a higher power density, enabling them to handle greater power levels within a more compact form factor. This characteristic is advantageous for space-constrained applications.
4. Response Time
CSP transformers respond much more quickly to load changes compared to conventional transformers. This rapid response makes them ideal for applications with fluctuating loads.
5. Flexibility
CSP transformers offer enhanced flexibility in input and output voltage ranges, allowing for a wider range of applications in different electrical systems.
6. Reliability
CSP transformers improve reliability and reduce the chances of failure and downtime compared to conventional models. This leads to more consistent performance and less maintenance.
7. Cost
CSP transformers can be more cost-effective in the long run due to their efficiency and reduced maintenance needs, despite potentially higher initial costs.
Conclusion
In summary, CSP transformers provide several advantages over conventional transformers, including higher efficiency, reduced size and weight, greater power density, faster response times, increased flexibility, and improved reliability. These benefits make CSP transformers a valuable choice in modern electrical applications.

Standard Features

This type of transformers are CSP type, which can protect itself from thunder and lighting, short circuit and protect the transiting and distribution line from current failure because of self-malfunction.
Except from some similarities such as cylinder tank, hooks, lifting lugs, grounding devices, nameplates, core and winding with the conventional type. This type of transformers have characteristics and devices as follows:
1) One or two high voltage bushings are on the cover with fuse.
2) One or two arresters are installed on the wall of the tank, whose top end is near to the high voltage bushing, and connected to the bushing by a copper strip. One secondary breaker switch is above the winding inside the tank, and here are operating handle,overload reset and signal light.
3) Low voltage bushing is educed from the wall of the tank, grounding device is fixed to position X2. One end of the single
bushing leads out through the high voltage bushing, the other end is ground connection.
4) All units are built in accordance with IEC60076, ANSI/IEEEC57.12.20, CSA C2.1-06,CSA C2.2-06 and etc.
