Inverted Motor Straight Line Wire Drawing Machine High Speed Frequency Conversion
Inverted Motor Straight Line Wire Drawing Machine High Speed Frequency Conversion
Inverted Motor Straight Line Wire Drawing Machine High Speed Frequency Conversion
Inverted Motor Straight Line Wire Drawing Machine High Speed Frequency Conversion
Specifications
Brand Name :
OLT
Model Number :
OLT-SLWDM-02
Certification :
ISO9001
Place of Origin :
China
MOQ :
1set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10sets one month
Delivery Time :
15days after deposit
Packaging Details :
nude packing
Product name :
High speed frequency conversion straight line wire drawing machine
Inlet Wire  Dia. :
6.0mm
Outlet Wire Dia. :
2.0mm
Number of drawing capstan :
9
Motor :
Inverted motor
Single Power :
15kw
Max speed :
12m/s
Dia.of capstan :
400mm
Description

High speed frequency conversion straight line wire drawing machine

1. Straight line wire drawing machine description:

High effective,high drawing speed in normal production
Easy operation,delightful man-machine interface
Optimized design,high reliability,low faults ratio
High quality finish wire due to no sliding,no torsion in drawing
Clean production environment due to install dust remove and air blowing system
Equip with advanced motors,high efficiency and saving energy
Low noise level compare to old type drawing machine

2. Straight line wire drawing machine parameter:

Model Block Dia.(mm) Max. Draw Passes Max.Inlet Wire Dia. (mm) Min.Outlet Wire Dia. (mm) Motor Power (KW) Max.Outlet Speed(m/s) Noise Level (dBA)
LZ-200 200 ≤15 2.2 0.25 4.0-5.5 22 ≤81
LZ-250 250 ≤15 2.6 0.4 4.0-7.5 22 ≤81
LZ-300 300 ≤15 2.8 0.5 5.5-7.5 22 ≤82
LZ-350 350 ≤15 3.5 0.6 5.5-11 22 ≤82
LZ-400 400 ≤15 4.2 0.75 11-15 22 ≤82
LZ-450 450 ≤15 4.5 0.8 11-22 20 ≤82
LZ-500 500 ≤15 5.0 1.2 15-30 20 ≤82
LZ-560 560 ≤15 5.5-6.5 1.3 22-45 20 ≤82
LZ-600 600 ≤15 6.5-7.0 1.35 30-55 20 ≤82
LZ-650 650 ≤15 7.0 1.5 30-55 18 ≤82
LZ-700 700 ≤15 8.0 1.8 45-75 18 ≤82
LZ-750 750 ≤15 8.0 2.0 45-75 16 ≤82
LZ-800 800 ≤15 10 2.5 55-90 16 ≤82
LZ-900 900 ≤15 12 3.0 75-110 16 ≤82
LZ-1000 1000 ≤15 14 3.5 90-132 15 ≤82
LZ-1200 1200 ≤15 16 4.0 90-132 14 ≤82

3. Straight line wire drawing machine advantage:


PLC: Siemens
Touch screen: Siemens
Inverter: Yaskawa, Schneider, Siemens
Circuit breakers and contactors: Schneider

4. Wire Drawing Production Line:


pay-off stand----wire descaling machine (pre-treatment)----wire pointing machine----butt welding machine-----wire drawing machine----annealing machine ----spooler take-up

5. Straight line wire drawing machine character :

Error 0.1% accurate meter; fixed length automatic deceleration and parking; disconnection detection and automatic stop; any reel positive and negative jog and left and right linkage; various fault information and processing information display; various motion information monitoring. The mold-matching process, after the mold is worn, is automatically compensated by tuning, and it is not easy to break the wire. And with a jumper device can be freely removed from the reel to adapt to different processes. Remote control and remote diagnosis can be implemented based on industrial Ethernet according to user needs.

6. Company induction:

Hebei Oulite Import & Export Trading Co.,Ltd is engaged in producing and distributing wire mesh making machine products. We can provide you chain link fence machines, barbed wire machine, razor barbed wire machine, welded mesh rolling machine, welded mesh panel machine, nail making machine and so on. Our factory director,Mr Wang Fucai is the patent holder of new type razor barbed wire in China(Patent Certificate ZL02235742.4).
