2.5m width fully automatic crimped wire mesh weaving machine

Full-automatic crimped wire mesh machine mainly weaves little wire diameter.

The wire diameter range is 0.4mm-2mm, this machine includes mesh weaving machine, crimped wire machine, rolling mesh part and mould. The mesh hole size can be from 1.5mm to 20mm,the cross wore can be fed automatic and not manually.

It is with high speed and easy operating. And is spoken highly of our customers.

The finished product--crimped wire mesh is used in filtration, food screen and so on.

More details, pls check the followings:

Main machine:

Wire diameter: 0.4mm-2mm;

Mesh hole size: 1mm-2.5mm;

Mesh width, 1.3m, other mesh width can be customized;

Motor: 380V/50HZ

Type: Full automatic

Machine dimension: 2.2m *3.5m *1.5m

Characteristics:

High working speed and efficiency ,can produce crimped wire mesh with different wire diameter, easy to operate.

Theory

Motor drive the gear to make wire materials to be crimped, then weave mesh;the hole sizes are based on the molds’ details.

Usage

Producing crimped wire mesh.

Advantages

Easy to operate, cover a small area, high production, high safety coefficient, high stable, low noise, etc.

Service

We can arrange our engineer to your place to help you adjust the machine.

FAQ:

Q: How many years are your company engaged in the wire mesh machines?
A: More than 25 years. We have our own technology develop department and testing department.

Q: Can your company send your engineers to my country for machine installation, worker training?
A: Yes, our engineers went to more than 100 countries before. They are very experience

Q: What's the guarantee time for your machines?
A: Our guarantee time is 2 years since the machine was installed in your factory.

Q: Can you export and supply the customs clearance documents we need?
A: We have much experience for exporting. And we can supply the CE certificate, Form E, passport, SGS report etc, your customs clearance will be no problem.
