Square Decorative Stone Crusher Vibrating Crimped Screen Mesh
Square Decorative Stone Crusher Vibrating Crimped Screen Mesh
Square Decorative Stone Crusher Vibrating Crimped Screen Mesh
Square Decorative Stone Crusher Vibrating Crimped Screen Mesh
Specifications
Brand Name :
YUDA
Model Number :
crimped wire mesh
Place of Origin :
CHINA
MOQ :
100 Square Meter
Price :
Determine based on size and quantity
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200000 Square Meter/ day
Delivery Time :
3-10 day
Packaging Details :
Customized according to buyer's requirements
Product Name :
Crimped wire mesh
Key Words :
Crimped mesh
Technique :
Woven
Wire diameter :
Requirement
Hole shape :
Square Hole,as per requirement
Width :
customized
Surface :
Galvanised / Stainless Steel / PVC
Application :
Mining,coal factory,rail road,farm,BBQ
Description

Square Decorative Crimped Wire Mesh Stone Crusher Vibrating Crimped Screen Mesh

Manganese Steel Ore Screen is a screen product made by weaving manganese steel wire with a diameter of 1.6mm-12mm. It adopts the embedded (Mn65-Q) weaving method, with no prominent overlapping points of longitude and latitude, a flat surface, and uniform force distribution.
The Hardness is HB180-230, with good plasticity and toughness. When subjected to strong impact and friction, the surface undergoes strong work hardening due to plastic deformation, and the surface hardness value can be increased to HRC60 or above, thereby achieving high wear resistance, while maintaining high plasticity and toughness internally.
When the old surface wears down, a wear-resistant layer will form on the new surface, and its lifespan can reach 4-8 times that of a regular sieve. Therefore, it is mostly used in the large-scale coal mining industry and can also be used as a protective net for professional mechanical vibrating screening machines, drum screening machines, electromagnetic high-frequency screening machines, and asphalt mixers.
Material:
1) Stinless steel wire(201,202,302,304,304L,310,316,316L)
2) High carbon steel wire,low carbon steel,medium carbon steel,Mn steel wire.
3) Galvanized iron wire,galvanized steel wire,non-ferrous metal wire. Other materials are available on request.
Application:
Crimped wire mesh is used as fence or filters in a lot of industries;Heavy Duty Crimped wire mesh are also named Quarry Mesh,it is mostly used as screen in mining,coal factory,construction and other industries.

FAQ

Q: Are you manufacturer?
A: Yes, we are manufacturer for woven wire mesh. It is mainly used for architectural mesh and decorative mesh.
Q: Can you offer a sample?
A: Yes, we can offer a free sample 10x10cm if have stock. For some customized sample, it need to charge based on the size and quantity.
Q: How to ensure the quality?
A: We will check the quality and take photos when produce and before sending out goods. If need, we can also offer test report.
Q: The mesh size can be customized?
A: Yes, the mesh size can be offered as your requirement. Then you can use it directly and no need to cut again.

CHEMICAL COMPOSITION

Material C≤ Mn≤ Si≤ S≤ P≤ Cr≤ Ni Mo N
S31803(SAF2205) 0.03 2 1 0.02 0.03 21.0/23.0 4.50/6.50 2.50/3.50 0.08/0.20
00Cr22Ni5Mo3N
PHYSICAL PROPERTIES
Material σb(Mpa)≥ σs(Mpa)≥ δ(%)≥ Hardness (stiffness)
(HB) (HRC)
S31803(SAF2205) 620 450 25 290 30.5
00Cr22Ni5Mo3N

Square Decorative Stone Crusher Vibrating Crimped Screen MeshSquare Decorative Stone Crusher Vibrating Crimped Screen Mesh
