No Anti-Dumping Duty From Turkey / High Quality Alkaline Resistant Fiberglass Mesh
Fiberglass mesh cloth is commonly used in architecture, decoration and engineering, and its main uses include:
Wall reinforcement: Glass fiber mesh cloth can be applied to building walls to increase the crack resistance and impact resistance of the wall and prevent wall cracking.
Fire isolation: Because the glass fiber has high temperature resistance, it can be used to make fire isolation curtains and fire partitions to provide fire safety protection.
Floor reinforcement: During the floor laying stage, fiberglass mesh cloth can be used in combination with cement or other floor materials to enhance the bearing capacity and crack resistance of the floor.
Tile back reinforcement: During the tile laying process, glass fiber mesh cloth can be used to reinforce the back of the tile to prevent the tile from cracking and falling off.
Protection and filtration: Fiberglass mesh cloth can be used for protection and filtration applications, such as window bug nets, air conditioning filters, etc.
Item | Yarn(Tex) | Mesh | Density | Finished | Tensile | Woven | Content | ||||
Number | size(mm) | Count/25mm | weight | StrengthX20cm | Structure | of resin%(≥) | |||||
Warp | Weft | Warp | Weft | warp | Weft | (g/m2) | Warp | Weft | |||
NK4X5-140 | 134X2 | 250 | 4 | 5 | 6 | 5 | 140 | ≥1300 | ≥1350 | Leno | 18 |
NK10X10-145 | 250X2 | 700 | 1 0 | 1 0 | 2.5 | 2.5 | 145 | ≥1250 | ≥1700 | Leno | 20 |
NK5X5-145 | 134X2 | 350 | 5 | 5 | 5 | 5 | 145 | ≥1400 | ≥1500 | Leno | 18 |
NK4X5-150 | 134X2 | 300 | 4 | 5 | 6 | 5 | 150 | ≥1300 | ≥1300 | Leno | 18 |
NK5X5-160 | 134X2 | 400 | 5 | 5 | 5 | 5 | 160 | ≥1450 | ≥1600 | Leno | 18 |
NK4X4-160 | 134X2 | 300 | 4 | 4 | 6 | 6 | 160 | ≥1550 | ≥1650 | Leno | 18 |
NK4X5-165 | 134X2 | 350 | 4 | 5 | 6 | 5 | 165 | ≥1300 | ≥1300 | Leno | 18 |
NK4X4-170 | 134X2 | 350 | 4 | 4 | 6 | 6 | 170 | ≥1450 | ≥1700 | Leno | 18 |
NK4X5-200 | 134X2 | 500 | 4 | 5 | 6 | 5 | 200 | ≥1500 | ≥2200 | Leno | 18 |
NK4X5-280 | 200X2 | 600 | 4 | 5 | 6 | 5 | 280 | ≥1900 | ≥2850 | Leno | 20 |
NK4X5-300 | 200X2 | 700 | 4 | 5 | 6 | 5 | 300 | ≥2000 | ≥3000 | Leno | 20 |
1. 75g / m2 mesh fabric used in the reinforcement of thin slurry, to eliminate small cracks and
scattered throughout the surface pressure.
2. 110g / m2 mesh cloth is widely used in indoor and outdoor walls, prevent the various materials
(such as brick, light wood, prefabricated structure) of treatment or caused by a variety of expansion
coefficient of wall crack and break .
3. 145g/m2 mesh fabric used in the wall and be mixed in various materials (such as brick, light
wood, prefabricated structures), to prevent cracking and scatter the whole surface pressure,
especially in the external wall insulation system (EIFS ).
4. 160g / m2 mesh fabric used in insulator layer of reinforcement in the mortar, through
shrinkage and temperature changes by providing a space to maintain movement between the
layers, prevent crack and rupture due to shrinkage or temperature change.
