10x10 Fiberglass Reinforcing Glass Fiber Mesh Cloth Fiberglass Wall Mesh
10x10 Fiberglass Reinforcing Glass Fiber Mesh Cloth Fiberglass Wall Mesh
10x10 Fiberglass Reinforcing Glass Fiber Mesh Cloth Fiberglass Wall Mesh
10x10 Fiberglass Reinforcing Glass Fiber Mesh Cloth Fiberglass Wall Mesh
Specifications
Brand Name :
YUDA
Model Number :
Glass fibre mesh
Certification :
IOS
Place of Origin :
CHINA
MOQ :
100 Square Meter
Price :
Further discussion based on the purchase quantity
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000 rolls/ day
Delivery Time :
3-10 day
Packaging Details :
Customized according to buyer's requirements
product name :
fiberglass mesh
Key words :
Reinforced Fiberglass Mesh Netting For Concrete Fiberglass mesh plaster Net
Material :
Fiberglass Yarn
Size :
can be custom made
Colors :
White,Yellow ,blue
Apertue :
4*4mm,5*5mm etc.
Coating :
Emulsion coated, Urea glue coated
Description

10x10 Fiberglass Reinforcing Glass Fiber Mesh Cloth Fiberglass Wall Mesh

Glass fiber mesh fabric, as a high-performance composite material, is mainly woven from high-strength glass fiber filaments, and its surface is often coated with resin coatings that are alkali resistant or waterproof. This material has been widely used in multiple industrial fields due to its unique physical and chemical properties. Fiberglass mesh fabric not only has excellent tensile strength and deformation resistance, but also has good corrosion resistance and weather resistance, making it an indispensable and important material in modern construction, transportation, shipbuilding, and environmental engineering fields.
Wall reinforcement: As a reinforcement layer of the wall insulation system, it improves the overall strength and stability of the wall.
External wall insulation: Used in combination with insulation materials to effectively prevent cracking and enhance insulation effectiveness.
Roof waterproofing: As a reinforcement material for the waterproof layer, it improves the durability and crack resistance of the waterproof layer.
traffic engineering
Road reinforcement: used for road surface repair and reinforcement to improve road bearing capacity and service life.
Bridge construction: As a reinforcement material for bridge structures, it enhances the stability and durability of the structure.
Ship manufacturing
Ship repair: Used for repairing and reinforcing the surface of the ship to prevent seawater erosion.
Interior Decoration: As the base material for ship interior decoration, it provides strength and aesthetics.
Environmental Protection Engineering
Landfill Cover: As a cover layer, it prevents environmental pollution caused by leachate from garbage.
Water treatment facilities: used as reinforcement layers in sewage treatment tanks and other facilities to improve structural strength.
Lightweight and easy to install
Compared to traditional metal materials, fiberglass mesh fabric is lightweight, flexible, and easy to transport and install. Construction personnel can easily perform cutting, splicing, and fixing, greatly improving construction efficiency and reducing labor intensity.
Breathable and Waterproof
Although fiberglass mesh fabric itself has a certain degree of breathability, the specially treated coating can effectively prevent moisture infiltration, achieving a perfect combination of breathability and waterproofing. This feature is particularly important in areas such as wall insulation and roof waterproofing.

Environmentally friendly and sustainable
The production process of fiberglass mesh fabric is relatively environmentally friendly, and the material itself can be recycled and reused, which is in line with the sustainable development concept of modern society. At the same time, its excellent durability reduces the need for frequent material replacement, further reducing its impact on the environment.
Reinforced Fiberglass Wall Mesh Specification:
Item Number Yarn(Tex) Mesh(mm) Density Count/25mm Tensile Strength × 20cm Woven Structure Content of resin%
Warp Weft Warp Weft Warp Weft Warp Weft
45g2.5x2.5 33×2 33 2.5 2.5 10 10 550 300 Leno 18
60g2.5x2.5 40×2 40 2.5 2.5 10 10 550 650 Leno 18
70g 5x5 45×2 200 5 5 5 5 550 850 Leno 18
80g 5x5 67×2 200 5 5 5 5 700 850 Leno 18
90g 5x5 67×2 250 5 5 5 5 700 1050 Leno 18
110g 5x5 100×2 250 5 5 5 5 800 1050 Leno 18
125g 5x5 134×2 250 5 5 5 5 1200 1300 Leno 18
135g 5x5 134×2 300 5 5 5 5 1300 1400 Leno 18
145g 5x5 134×2 360 5 5 5 5 1200 1300 Leno 18
150g 4x5 134×2 300 4 5 6 5 1300 1300 Leno 18
160g 5x5 134×2 400 5 5 5 5 1450 1600 Leno 18
160g 4x4 134×2 300 4 4 6 6 1550 1650 Leno 18
165g 4x5 134×2 350 4 5 6 5 1300 1300 Leno

18
