Wire Rope Flexible Stainless Steel Mesh Anti Falling Net 1*7 Specification
Wire Rope Flexible Stainless Steel Mesh Anti Falling Net 1*7 Specification
Wire Rope Flexible Stainless Steel Mesh Anti Falling Net 1*7 Specification
Wire Rope Flexible Stainless Steel Mesh Anti Falling Net 1*7 Specification
Specifications
Brand Name :
Yuntong
Model Number :
YT-S-1617
Certification :
CE , SGS
Place of Origin :
Hengshui, Hebei, China
MOQ :
10 square meters
Payment Terms :
T/T, Western Union,PayPal, L/C
Supply Ability :
300 Sqm / week
Delivery Time :
About 5-8 Work Days
Packaging Details :
Package water-proof film inside then carton box outside
Material :
AISI 316L
Wire Rope :
2.0mm, 2.4mm is popular
Mesh Opening :
From 50x50 to 100x100mm or bigger
Product Name :
Stainless Steel Rope Mesh For Protection
Mesh Angle :
Diamond shape at 60 degree angle
Usage :
Balustrade , railing , architecture
Feature :
Flexible, High tensile, Light weight
Description

Stainless Steel Wire Rope Net For Anti-falling Net With Ferrule

Ferruled wire rope mesh with high quality is manufactured from high-grade stainless steel cables of material class 1.4401, AISI316 / AISI316L ;
X-TEND stainless steel cable mesh is custom manufactured to suit your balustrade, railing or architecture application ;
Finished diamond mesh style when it is stretched at 60 degree angle Mesh can be applied in either a vertical or horizontal direction, again dependent on the balustrade or railing design. Mesh sizes range from 25mm x 25mm to 250mm x 250mm with stainless cable diameters from 1.2mm to 3.2mm.

Wire Rope Mesh Specifications :

Hole Size

(Opening)

1.2MM(3/64)

(7 x 7 )

1.6MM(1/16)

(7 x 7 )

2.0MM(5/64)

(7 x 7 )

2.4MM(3/32)

(7 x 7 )

3.2MM(1/8)

(7 x 19 )
20 x 35mm YT-1235
25 x 42mm YT-1225 YT-1625
30 x 52mm YT-1230 YT-1630 YT-2030
35 x 60mm YT-1235 YT-1635 YT-2035
38 x 66mm YT-1238 YT-1638 YT-2038 YT-2438
40 x 69mm YT-1240 YT-1640 YT-2040 YT-2440 YT-3040
50 x 86mm YT-1250 YT-1650 YT-2050 YT-2450 YT-3050
60 x 104mm YT-1260 YT-1660 YT-2060 YT-2460 YT-3060
70 x 120mm YT-1270 YT-1670 YT-2070 YT-2470 YT-3070
76 x 131mm YT-1276 YT-1676 YT-2076 YT-2476 YT-3076
80 x 138mm YT-1280 YT-1680 YT-2080 YT-2480 YT-3080
90 x 154mm YT-1290 YT-1690 YT-2090 YT-2490 YT-3090
100 x 173mm YT-12100 YT-16100 YT-20100 YT-24100 YT-30100
120 x 206mm YT-12120 YT-16120 YT-20120 YT-24120 YT-30120

Packaging & Delivery:


Packaging Details: Plastic film inside wooden box outside
Delivery Time: Within 10-15 days after we receive the deposit

Features Of The Stainless Steel Rope Mesh:


1. Corrosion resistance, anti-soft resistance,
2. Breaking force, impact resistance,
3. Durable structure, beautiful appearance,
4. New form, one-time investment, permanent use,
5. Does not require any maintenance etc.

Stainless Steel Wire Rope Mesh Type:


1. Knotted Mesh
2. Ferruled Mesh

Our Services About The Wire Rope Mesh:

1. Free sample for you!
2. Customer request is available!
3. Any question, please feel free to contact us. We can assure you, any of your comments will get our prompt reply. We will do our best to serve you
4. Our products are strictly follow ISO9001, SGS, CE and BV certificate. If any item do not meet your request, we will replace for your by free!
Wire Rope Flexible Stainless Steel Mesh Anti Falling Net 1*7 Specification
