Sky Blue BV BVV Wire Extruder Machine With 150kg Extrusion Output ISO Certified
Sky Blue BV BVV Wire Extruder Machine With 150kg Extrusion Output ISO Certified
Sky Blue BV BVV Wire Extruder Machine With 150kg Extrusion Output ISO Certified
Sky Blue BV BVV Wire Extruder Machine With 150kg Extrusion Output ISO Certified
Sky Blue BV BVV Wire Extruder Machine With 150kg Extrusion Output ISO Certified
Sky Blue BV BVV Wire Extruder Machine With 150kg Extrusion Output ISO Certified
Sky Blue BV BVV Wire Extruder Machine With 150kg Extrusion Output ISO Certified
Sky Blue BV BVV Wire Extruder Machine With 150kg Extrusion Output ISO Certified
Specifications
Brand Name :
Fuchuan
Model Number :
FC-70+40-7
Certification :
ISO9001:2008
Place of Origin :
China JiangSu
MOQ :
1set
Price :
USD83300
Payment Terms :
T/T, L/C
Supply Ability :
500 SETS PER YEAR
Delivery Time :
45days
Packaging Details :
normal packing
color :
sky blue
pay off bobbin :
DIA 500/630/800/1000mm
fit for wire :
BV,BVR,RV,PE,BVV
wire :
enamelled wire/glazed wire/insulated wire
BV building wire :
AND LAN cable ALSO
Wire Dia :
1.5-12mm
plastic material :
PVC.PE
screw dia :
50/60/70/80/90
Description

China FUCHUAN BV BVV Wire Extruder Machine With 150kg Extrusion Output ISO Certified

Quick Details:

BV,BVV,BVR,RV wire extruder production line

A. Apply for extruding the PVC,PE and other plastic material for the BV,BVR insulate sheathing produced.

Characteristics:

A. PLC+IPC operation or touch screen operation, save, display and change all kinds technological parameters. Whole-process monitor.

B. Superior special non-adjusted head, meet the extruder technological parameters requirement.

C. High speed pay off equipment, assure unload the bobbin do not stop machine.

D. Special extruder screw, meet the kinds of material requirement.

Specification:

Model FC-50 FC-60 FC-70-7 FC-80
Screw Diameter Φ50 Φ60 Φ70 Φ80
Screw L/D Ratio 26:1 26:1 26:1 25:1
Feed wire type Active pay off or tension pay off
Max speed(m/min) 300 300 300 200
Extrusion output 70 100 150 200
Power for main machine(KW) 15 18.5 30 37
Wire diameter Φ0.6-4.0 Φ0.8-8.0 Φ1.5-12 Φ5.0-20
Max accumulator length(m) 220
Accumulator Horizonal accumulator
Cooling channel Folding W type or U type
Capstan diameter Φ410 Φ410 Φ510 Φ610
Capstan power 3.7KW 3.7KW 5.5KW 7.5KW
Take up power 3.7KW 5.0KW 7.5KW 3.7KW reduction motor
Take up type Double shaft take-up

Other Information

FOB SHANGHAI
Payment

TT, L/C
Delivery

FOB Shanghai/Ningbo
Origin

China
Minimum Order

1 set
Package
with container
