Automobile Wire / Plastic Insulating Wire Extrusion Machine With Screw Dia 60mm
Automobile Wire / Plastic Insulating Wire Extrusion Machine With Screw Dia 60mm
Automobile Wire / Plastic Insulating Wire Extrusion Machine With Screw Dia 60mm
Automobile Wire / Plastic Insulating Wire Extrusion Machine With Screw Dia 60mm
Automobile Wire / Plastic Insulating Wire Extrusion Machine With Screw Dia 60mm
Automobile Wire / Plastic Insulating Wire Extrusion Machine With Screw Dia 60mm
Automobile Wire / Plastic Insulating Wire Extrusion Machine With Screw Dia 60mm
Automobile Wire / Plastic Insulating Wire Extrusion Machine With Screw Dia 60mm
Specifications
Brand Name :
Fuchuan
Model Number :
FC-60+35-6
Certification :
ISO9001:2008
Place of Origin :
China JiangSu
MOQ :
1set
Price :
DISCUSSABLE
Payment Terms :
T/T, L/C
Supply Ability :
500 SETS PER YEAR
Delivery Time :
45days
Packaging Details :
normal packing
screw dia :
60mm
color :
sky blue
screw ratio :
25:1
extrusion output :
100kg
max speed :
600m/min
pay off bobbin :
DIA 500/630/800/mm
Material :
PVC,PP,PE,SR-PVC
Description

Automobile Wire / Plastic Insulating Wire Extruder Machine With Screw Dia 60mm

Quick Details:

Automobile wire high speed extruder line

1. Apply for extruding the PVC,PP,PE,SR-PVC and other plastic material for the automobile wire,insulated jacketed.

Characteristics:

Component:

2.1 Lut barrel up pay off machine,straighten ,main machine,injection machine,control case,water tank,double

2.2 wheel capstan,accumulator,double shaft take up and other equipments.

The choice equipments:

2.3 copper wire pre-heater,printer,OD measuring instrument,spark tester and PLC control or IPC operation. Save,display and revise technology parameter,remote control.

Specification:

3.1. Mechanical model: FC-60+35-6

3.2. Pay off type: 500-630active pay off or lut barrel up pay off

3.3. Screw dia: 60

3.4. Screw ratio: 25:1

3.5. Extrusion output: 100kg/h

3.6. Revolving speed of screw: max 100rpm

3.7. Main power: 15kw

3.8. Wire diameter: 0.8-5.0mm

3.9. Cooling device: monolayer/double layer model U

4.0. Take up type:1246 automatic coiling machine,the plum blossom falls barrel machine,shaft type.

Other Information

FOB SHANGHAI
Payment

TT, L/C
Delivery

FOB Shanghai/Ningbo
Origin

China
Minimum Order

1 set
Package
with container
