Specifications
Brand Name :
Fuchuan
Model Number :
FC-650B-3
Certification :
CE
Place of Origin :
China
MOQ :
1set
Price :
USD27666
Payment Terms :
T/T, L/C
Supply Ability :
500 SETS/YEAR
Delivery Time :
45days
Packaging Details :
simply packed
Color :
apple green
Fit for bobbin :
DIA 630mm
Fit copper wire :
0.12mm to 0.52mm
Wire :
core wire,bare copper wire,tinned wires,silver jacketed wires
soft wire :
flexible wire/ insulated wire
brake mode :
electromagnetic brake
operation mode :
touch screen
Description

FUCHUAN high speed apple Green Copper Wire Bunching Machine , Cable Machinery

Quick Details:

Japan Technology, product in China

FUCHUAN® Series for Model B normal wire high speed bunching machine and double twist bunching machine

New arrival, mainly apply for stranding the electrical wire and automobile wire and other small section area conductor.

Characteristics:

a) With high rotation speed, with constant tension from empty bobbin to full bobbin, with superior quality for twist wire,

b) The machine is driven by synchronization strap.

c) Only need to change the capstan wheel to change the pitch.

d) Easy to operate.

Specifications:

Equipment models FC-500B FC-650B-3 FC-650C FC-800B
Twisting usage Apply for twisting aerospace, medical equipment, cellphone and ultra conductor(above seven pcs of bare copper wires, tinned wires, silver jacketed wires and enameled wires),double twisting for core wires.
Single wire dia(mm) 0.08-0.45 0.15-1.04 0.12-0.52 0.38-1.70
Stranding section area (mm²) 0.05-2.5 0.35-6.0 0.30-4.0 1.0-16
Core wire single wire dia(mm) 0.5-1.5 0.5-3.0 0.5-2.0 1.0-4.0
Core wire stranding outer dia(mm) 1.0-3.5 1.0-6.0 1.0-4.0 2.0-8.0
Pitch(mm) 6.3-52.3(24classes) 11.6-100(34classes) 11.6-100(34classes) 23-147(20classes)
Direction of lay Optional for right or left
Outer dia*bore*outer width OD500 ID56 H375 OD630 ID56 H475

OD630 ID56 H475

OD630 ID127 H475

OD800 ID80 H600
Max rotating speed 3000rpm(6000twist) 2000rpm(4000twist) 2400rpm(4800twist) 1500rpm(3000twist)
Main motor power 5.5KW 7.5KW 11KW 15KW
Inverter power 5.5KW 7.5KW 11KW 15KW
Tension control method Touch screen +PLC+ magnetic powder clutch, ensure the constant tension from empty to full bobbin
Magnetic powder clutch 1.2kgf 5kgf 2.5kgf 10kgf
Protection

automatically brake/stop 1)wire inside and outside is broken

2)the preset length is arrived
Brake mode Electromagnetic brake
Traversing method Rolling wire with ring drive units, winding pitch and breadth are adjustable
Operation mode Touch screen operation
Dimension(mm) 2680L 1250W 1500H 3300L 1550W 1800H 3300L 1550w 1800H 4600L 2000W 2000H

Other Information

FOB SHANGHAI
Payment

TT, L/C
Delivery

FOB Shanghai/Ningbo
Origin

China
Minimum Order

1 set
Package
with container
