Specifications
Brand Name :
Fuchuan
Model Number :
FC-70+40
Certification :
ISO9001:2008
Place of Origin :
China JiangSu
MOQ :
1set
Price :
Negotaiable
Payment Terms :
T/T, L/C
Supply Ability :
500 SETS PER YEAR
Delivery Time :
60-90days
Packaging Details :
simple water-prof packing
color :
sky blue
pay off bobbin :
Diameter 630/800/1000mm
fit for wire :
automotive wire
wire :
enamelled wire/glazed wire/insulated wire
Monitor :
LCD monitor
screw dia :
70
plastic material :
PVC.PE
Description

FC-70+40 automotive Wire Screw Extruder Machine 500M/min for 1-6 square meter

Quick Details:

PVC PE wire insulated and sheathing

Usage:

It is applied to extrude the PVC,PE and other plastic material for the automotive wire insulated and sheathing produced.

Characteristics:

  1. PLC+IPC operation or touch screen operation, save, display and change all kinds technological parameters. Whole-process monitor.
  2. .Superior special non-adjusted head, meet the extruder technological parameters requirement.
  3. Special extruder screw, meet the kinds of material requirement.
  4. High speed pay off equipment, assure unload the bobbin do not stop machine.

Specification:

Model FC-50 FC-60 FC-70+45 FC-80
Screw Diameter Φ50 Φ60 Φ70 Φ80
Screw L/D Ratio 26:1 26:1 26:1 25:1
Feed wire type Active pay off or tension pay off
Max speed(m/min) 300 300 300 200
Extrusion output 70 100 150 200
Power for main machine(KW) 15 18.5 30 37
Wire diameter Φ0.6-4.0 Φ0.8-8.0 Φ1.5-12 Φ5.0-20
Max accumulator length(m) 220
Accumulator Horizonal accumulator
Cooling channel Folding W type or U type
Capstan diameter Φ410 Φ410 Φ510 Φ610
Capstan power 3.7KW 3.7KW 5.5KW 7.5KW
Take up power 3.7KW 5.0KW 7.5KW 3.7KW reduction motor
Take up type Double shaft take-up

Other Information

FOB SHANGHAI
Payment

TT, L/C
Delivery

Shanghai SEA PORT
Origin

China
Minimum Order

1 set
Package
with container
