Specifications
Brand Name :
FUCHUAN
Model Number :
FC-T24
Certification :
ISO9001 2008
Place of Origin :
CHINA
MOQ :
1SET
Price :
USD24330
Payment Terms :
T/T, L/C
Delivery Time :
8weeks
Packaging Details :
simply water proof packing
Supply Ability :
500sets per year
number of inlet wire :
24pcs
machine color :
sky blue or apple green
fit for wire :
0.08-0.25mm or 0.15-0.64
pay off bobbin :
diameter 300mm
annealing method :
tube annealing
max speed :
300m/min
pay off method :
brush pay off
Description

Flexible Alloy Wire Tube Annealing Machine 61Kw Water Seal Protection

Quick detail:

Normal wire high speed annealing machine

Characteristic:

Easy to operate, good annealing heat preservation, save electricity, achieve industry-leading level.

Specification:

Equipment models FC-T24
Twisting usage It is mainly applied to the annealing of ultra-fine round copper wire and alloy wire.
Single wire dia(mm) φ0.08-φ0.25 or φ0.15-φ0.64mm
Max numbers of inlet wire 24pcs
Linear speed Max:300m/min
Pay off method Brush pay off
Pay off bobbin model φ300bobbin
Annealing furnace length 3.5m or 6m
Annealing method Tube annealing
Annealing protection method Water seal protection
Tinned method Hot dip
Capstan control method Inverter+ motor control or adopt stepless speed regulation motor
Equipment total power 61kw
Take up control Take up is voltage regulator control the moment motor
Take up bobbin size 5inch,8inch bobbin or 5inch,8inch,10inch bobbin
Traverse control method Stepless speed regulation motor+ turbine gear box control toothrow traverse
Installation size 145000L*1500W*2100H
