Cantilever Type Rubber Extrusion Line , Cable Vulcanizing Machine 300kg/H Max Output
Cantilever Type Rubber Extrusion Line , Cable Vulcanizing Machine 300kg/H Max Output
Cantilever Type Rubber Extrusion Line , Cable Vulcanizing Machine 300kg/H Max Output
Cantilever Type Rubber Extrusion Line , Cable Vulcanizing Machine 300kg/H Max Output
Cantilever Type Rubber Extrusion Line , Cable Vulcanizing Machine 300kg/H Max Output
Cantilever Type Rubber Extrusion Line , Cable Vulcanizing Machine 300kg/H Max Output
Cantilever Type Rubber Extrusion Line , Cable Vulcanizing Machine 300kg/H Max Output
Cantilever Type Rubber Extrusion Line , Cable Vulcanizing Machine 300kg/H Max Output
Specifications
Brand Name :
Herrman
Model Number :
XJ-120/16
Certification :
ISO9001:2015,CE
Place of Origin :
China
MOQ :
1set
Price :
By Negotiation
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
15 sets per month
Delivery Time :
120 working days
Packaging Details :
Seaworthy packing suitable for export
Name :
Rubber Continuous Vulcanizing Line
Usage :
Extrusion
Capstan type(XJ-90/16) :
TQDV2000
Rubber materials :
natural rubber, EPR, EPDM, EVA, CPE, EPOM,CR, Silicone Rubber and so on
Linear speed :
60m/min
Max. extruding speed (m/ming speed (XJ-90/16) :
30
Max. output :
300kg/h
Motor :
SIEMENS
Bearing :
NSK
Color :
Customized
Warranty :
1 year
Description

Rubber extrusion line rubber extruder cantilever type extruder

Description

Rubber Continuous Vulcanizing Line is a special machine for the purpose of insulating, sheathing and continuous vulcanizing rubber wire and cable. The rubber materials include natural rubber, EPR, EPDM, EVA, CPE, EPOM,CR, Silicone Rubber and so on. The cable which is made by this machine can be used in mining, marine, shipboard etc.

Main Specification

ITEM XJ-90/16 XJ-120/16 XJ-150/16 XJ-65/14+XJ-90/16 XJ-90/16+XJ-120/16 XJ-65/16+XJ-120/16+XJ-90/16 XJ-90/16+XJ-150/16+XJ-120/16
Dia. before extruding (mm) Φ5~Φ20 Φ12~Φ50 Φ20~Φ8 Φ5~Φ30 Φ15~Φ80 Φ15~Φ80 Φ20~Φ90
Dia. after extruding (mm) Φ30 Φ60 Φ90 Φ40 Φ90 Φ90 Φ110
Max.extruding speed (m/min) 30 30 20 30 20 20 20
Max. output (kg/h) 150 380 550 70+150 150+380 70+150+380 150+550+380
Heating area 5 6 6 5+5 5+6 5+5+6 5+6+6
P/O reel Φ1600 Φ2500 Φ2500 Φ2000 Φ2500 Φ2500 Φ2500
T/U reel Φ2500 Φ3150 Φ3150 Φ2500 Φ3150 Φ3150 Φ3150
Capstan type TQDV2000 TQDV2500 TQDV3000 TQDV2000 TQDV3000 TQDV3000 TQDV3000

Drawing for reference

Cantilever Type Rubber Extrusion Line , Cable Vulcanizing Machine 300kg/H Max Output
